Page 181 - 2018 Master Catalog

THRUST BEARINGS
& WEAR PLATES
• Wear plates are moly coated
GM LS FRONT COVERS • Eliminates wear at front of block
Feature provisions for timing pointer, OEM camshaft • Unique designs help set proper cam
sensor and any regular BBC crank trigger. thrust clearance
PART NO. DESCRIPTION PART NO. DESCRIPTION
5496 LS Front Cover ( LS1, LS2, LS3, LS6 ) 201 Chevy V8 265-400 Wear Plate (.030” Bearing Thickness)
5497 LS Front Cover ( LS7 ) 203 Chevy V8 396-454 Wear Plate (.030” Bearing Thickness)
203 Chrysler V8 383-440 Hemi Wear Plate (.030” Bearing Thickness)
Ford V8 289-351W Thrust Plate & Bearings OEM Replacement for Cam Plate
3120TB
MAGNUM CHECKING PUSHRODS Single Bearing (.142” Bearing Thickness)
3122TB Ford V8 351C, 429-460 Thrust Plate & Bearings (.142” Bearing Thickness)
Make it easy and economical to lay out and determine proper
pushrod length during a high performance engine rebuild.
THRUST BUTTONS
PART NO. DESCRIPTION FROM TO
• Rides between the front of the timing gear and
7901-1 Individual Length Checker 7.500” 8.700” back of the timing cover
• Can be shimmed for proper endplay
• Solid nylon and roller thrust bearing styles available
HI-TECH™ CHECKING PUSHRODS PART NO. DESCRIPTION
Unique design is easy to read and eliminates the need for
expensive calipers. Each complete revolution is equal to .050”. 202 Chevy V8 265-400, 90° V6 Nylon Thrust Button (.810” Length)
200 Chevy V8 265-400 Roller Button (.795” Length)
PART NO. DESCRIPTION FROM TO 205 Chevy V8 396-454 Nylon Thrust Button (.945” Length)
207 Chevy V8 396-454 Roller Button (.945” Length)
7702-1 Individual Length Checker 6.800” 7.800” 204 Chrysler V8 Hemi Roller Buttons (.715” Length)
7703-1 Individual Length Checker 7.800” 8.800” 206 Chrysler V8 Hemi, 383-440 Nylon Thrust Button (.735” Length)
HIGH ENERGY™ PUSHRODS

• Best choice when building street rods, RVs or daily driver engines
• Available in 3/8” or 5/16” diameters
• Meet or exceed all OE pushrod specifications
• Mate perfectly with High Energy™ or Magnum Rockers
USE WITH
PART NO. DESCRIPTION GUIDE PLATES DIAMETER LENGTH END TYPE

7816-12 Chevy V6 173 (60°), 1980-86 Yes 5/16” 6.165” H-H
7808-16 Chevy V8 262-400 w/ OE Hydraulic Roller Cam 1987-Present Yes 5/16” 7.205” H-H
7809-16 Chevy V8 262-400 w/ Retro-Fit Hydraulic Roller Cam 1955-Present Yes 5/16” 7.266” H-H
7812-16 Chevy V8 262-400, 1955-Present w/ Flat Tappet Yes 5/16” 7.794” H-H
7815-16 Chevy V8 396-454 Retro-Fit Pushrod Set, Intake & Exhaust 1965-Present Yes 3/8” 7.725” Int. 8.684” Ext. H-H
7854-16 Chevy V8 396-454, 1965-86 (Standard Length, Standard Block) Yes 3/8” 8.280” Int. 9.252” Ext. H-H
7831-16 Ford V8 255 & 302, 1965-Present w/ Flat Tappet Yes 5/16” 6.881” H-H
7826-16 Ford V8 302 w/ OEM Hydraulic Roller Cam 1985-Present Yes 5/16” 6.248” H-H
7819-16 Ford V8 302 Retro-Fit Hydraulic Roller Yes 5/16” 6.400” H-H
7835-16 Ford V8 351W, 1969-78 No 5/16” 8.152” H-H
7823-16 Ford V8 351W Retro-Fit Hydraulic Roller Yes 5/16” 7.694” H-H
7820-16 Chrysler V8 273-360, 1964-86 No 5/16” 7.500” B-B
7821-16 Chrysler V8 273-360, 1964-86 Hyd. Cam w/ Adjustable Rockers No 5/16” 7.389” A-B
7851-16 Pontiac V8 350-455, 1955-79 Yes 5/16” 9.146” H-H

HI-TECH™ PUSHRODS
• Precision formed and reinforced 5/16” ball type ends
• One-piece construction from .080” wall seamless chromemoly • Black oxide finished and laser etched part number & length
• Heat-treated for extended durability & guide plate compatibility • Ideal for serious street performance and race applications
PART NO. DESCRIPTION WALL THICKNESS DIAMETER LENGTH

7972-16 Chevy Small Block, Standard Length .080” 5/16” 7.800”
7993-16 Chevy Small Block, +.100” Long .080” 5/16” 7.900”
7955-16 GM Gen III/LS1/LS2/LS6, Standard Length .080” 5/16” 7.400”

181
