RTD-1 Retard Control MAP Sensor Harness Kit

CD-1™ CAPACITIVE DISCHARGE
IGNITION SYSTEM
• 135 MJ spark energy output
• Built-in data logging capability with
16 Mbit DataFLASH memory
• Dedicated input terminals for launch RPM TCS-1™ TIMING CONTROL
and manifold pressure
SYSTEM FOR RACING
PART NO. DESCRIPTION
• Versatile timing control system for race engines.
Eliminates need for mechanical advance
102003 CD-1 Ignition System Kit (Includes P/N 102001, 102002, and 102004) • Preprogrammed with 20° advance curve between
102004 USB Interface (required for custom programming and data logging capability) 1,000 and 3,000 RPM for V8 engines. Helps
102005 RTD-1 Retard Control provide easier starting and smoother idle
102006 MAP Sensor harness Kit • Magnetic pickup and module trigger inputs
102007 Power Filter Capacitor Kit
PART NO. DESCRIPTION
102008 TCS-1 Timing Control System (w/ preprogrammed advance curve)
CD-1™ MARINE CAPACITIVE
DISCHARGE IGNITION SYSTEM
• Compatible with 8-cylinder marine engines
w/ distributor type ignition SL-1™ SHIFT LIGHT CONTROLLER
• 135 mJ spark energy output AND DATA LOGGER
• PC programmable idle stabilization feature
• Built-in data logging capability with 16 Mbit • Ultra-high brightness red/green/blue LED display
Data FLASH memory that can be mounted or attached to a tach
w/ a supplied bracket
PART NO. DESCRIPTION • Launch and multi-stage shift light capability
• Two independent programmable alarm functions
103003 CD-1 Marine Ignition Kit (Includes P/N 103001, 103002, and 102004) for analog inputs
• Heavy duty industrial grade clamping terminal
blocks allow easy and reliable hookup w/o
soldering or crimping
WEGO™ IV DUAL DISPLAY WIDE-BAND PART NO. DESCRIPTION
AIR/FUEL RATIO METER SYSTEM
117001 SL-1 Vehicle Data Logger and shift light
• Displays Lambda or correct AFR values
for any hydrocarbon fuels with a known
stoichiometric ratio
• Can be used for on-road or dyno testing
• Easy free-air calibration procedure corrects TC-1™ TURBO CONTROLLER
for sensor aging effects
AND VEHICLE DATA LOGGER
PART NO. DESCRIPTION

113001 WEGO IV Dual Channel Wide-Band AFR Kit

WEGO™ IV WIDE-BAND AIR/FUEL RATIO
METERS W/ DISPLAY & DATA LOGGING • Open and closed loop control modes. Includes programmable duty cycle or boost curves
based on RPM, vehicle speed and or time
• Wide supply voltage range from 11-16V • Built-in 4-bar MAP sensor. User selectable units
allows operation from battery on small
engines and race vehicles w/o an alternator • Bright transflective LCD display with backlight is readable in direct sunlight
• Built-in USB interface • 0-5V analog inputs are compatible with Daytona Sensors single or dual channel WEGO
• 0-5V analog AFR output for interface to dyno units for logging wide-band air/fuel ratio data
instrumentation PART NO. DESCRIPTION
PART NO. DESCRIPTION
118001 TC-1 Turbo Controller and Vehicle Data Logger
118002 Boost Control Solenoid Valve
114001 WEGO IV Wide-band AFR Kit
