measures, in the process control system that will assessment, develop and/or agree upon procedures
maintain safe operations during chemical unloading for chemical unloading and emergency operations
activities. The control system should monitor to ensure responsibilities are clearly defined.
and respond to hazardous process conditions Procedures should establish a process that requires
(e.g., temperature, level, pressure, or airborne facility personnel to be physically present during
concentrations) and automatically shut down the deliveries. Both facility personnel and drivers should
transfer of chemicals and other processes in the event verify (i.e., verbally and visually, through written
of an unintended reaction or release during chemical checklists, and/or during equipment walk-downs)

unloading. Where automated process control and a correct connection before discharging chemicals.
safety systems are not feasible, configure transfer Management of both facilities and chemical
valves and equipment, as well as ventilation, deluge, distributors should provide effective initial and
and other mitigation systems, so that they can be refresher training on the procedures periodically,
activated remotely to stop the flow of chemicals into or when equipment or chemicals are modified. In
facility piping or receiving tanks during an emergency. addition, management should actively monitor
3. Design or modify chemical transfer equipment procedures to ensure conformance.

to ensure fill lines for incompatible materials are 7. Evaluate building design and ventilation systems for
physically separated by a discernable distance (e.g., occupied structures near chemical unloading stations
acids delivered to an unloading area separate from to ensure occupants are protected in the event of
bases) to avoid reactive incidents resulting from a spill or chemical reaction. Design considerations
inadvertent mixing. should include positive-pressure ventilation systems,
4. Work with chemical distributors to select hose couplings makeup air-cleaning and filtration systems, sensors
and fill line connections with uniquely shaped and color- and alarms that automatically shut down HVAC
coded fittings for each chemical or class of chemicals, systems in the event of a release, and the careful
especially where several chemicals are unloaded in close selection of intake locations to prevent chemicals from

proximity. This can include a combination of accepted entering the supply. These systems should be checked
fittings with unique shapes (e.g., square for acids, hexagon regularly to ensure they are functioning properly.
for bases) or different sized diameters (e.g., 2-inch or 3-inch 8. For all occupied buildings near chemical unloading
round) for each fill line. areas and bulk storage tanks, evaluate the accessibility
5. Ensure pipe marking and identification of transfer of emergency respirators and escape bottles in the
equipment (e.g., fill lines, valves, transfer piping, and event of a toxic release. Avoid locking emergency
tanks) identification are clear and accurately represent respirator components in lockers, even between shifts,

the material contained in the equipment in accordance to ensure that workers can immediately access the
with accepted industry standards, such as ASME A13.1- equipment at all times. Conduct reviews of control
2007 Scheme for the Identification of Piping Systems. rooms and emergency evacuation routes to determine
Affix pipe markers as close to fill line connection points the most accessible location of employee respirators
as possible so that personnel involved in unloading near escape bottles and update emergency response
activities can easily identify equipment and chemicals and respiratory protection procedures and training
prior to making a connection. This is particularly accordingly.
important when there are multiple fill lines for different 9. Provide emergency escape respirators near chemical
chemicals in one area. unloading areas for drivers and personnel in the event

6. Work with chemical distributors to conduct a of a spill or unintended reaction and release during
risk assessment and, based on the results of the unloading operations.
