CARBIDE CARBIDE
END MILLS RECOMMENDED CUTTING CONDITIONS END MILLS RECOMMENDED CUTTING CONDITIONS

CARBIDE, 4 FLUTE BALL NOSE CARBIDE, 2 FLUTE TiAlN-COATED - SLOTTING

E5250, E5060, E5062, E5252 SERIES EH527 SERIES
P K N P M K N
MATERIAL CARBON STEELS CARBON STEELS IRON MATERIAL CARBON STEELS CARBON STEELS CARBON STEELS STAINLESS ALUMINUM COPPER. BRASS
ALLOY STEELS ALLOY STEELS CAST IRON RPM FEED ALLOY STEELS ALLOY STEELS ALLOY STEELS STEELS CAST IRON ALLOYS NON-FERROUS
TOOL STEELS TOOL STEELS ALUMINUM ALLOYS TOOL STEELS TOOL STEELS TOOL STEELS TITANIUM ALLOYS METALS
HARDNESS ~ HRc30 HRc30 ~ HRc40 HARDNESS ~ HRc 20 HRc 20 ~ HRc 30 HRc 30 ~ HRc 40
STRENGTH ~ 1000N/mm 2 1000 ~ 1300N/mm 2 STRENGTH 500 ~ 800N/mm 2 800 ~ 1000N/mm 2 1000 ~ 1300N/mm 2
DIAMETER RPM FEED RPM FEED RPM FEED RPM FEED DIAMETER RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED
3/32 5200 5.5 4400 2.8 7300 9.1 21500 16.5 2.0 7700 4.3 6720 3.9 5600 3.0 11200 3.5 9100 8.3 22400 17.7 16800 13.2
1/8 3500 5.9 2900 2.8 4900 9.5 14300 16.5 3.0 5180 4.9 4480 4.3 3640 3.4 7420 3.5 5880 8.3 15400 17.7 11200 13.2
5/32 2600 5.9 2100 2.8 3600 11.8 10900 16.5 4.0 3920 4.9 3360 4.3 2800 3.4 5600 3.5 4480 8.3 11200 17.7 8400 13.2
3/16 2100 6.3 1700 2.8 2900 13.8 8800 19.7 5.0 3080 4.9 2660 4.3 2240 3.4 4480 3.5 3500 8.3 8960 17.7 6720 13.2
1/4 1700 5.9 1430 2.8 2400 15.0 7260 19.7 6.0 2520 4.9 2240 4.3 1820 3.4 3640 3.5 2940 9.8 7420 18.7 5600 14.4
5/16 1270 5.5 1100 2.8 1800 18.9 5500 22.4 8.0 1960 4.9 1680 4.3 1400 3.4 2800 3.5 2240 10.4 5600 18.7 4200 14.4
3/8 1000 5.5 870 2.8 1430 18.9 4300 22.4 10.0 1540 4.9 1330 4.3 1120 3.4 2240 3.5 1820 11.0 4480 18.7 3360 14.4
1/2 870 5.1 730 2.8 1200 18.9 3600 26.0 12.0 1260 4.9 1120 4.3 924 3.4 1820 3.5 1400 11.6 3640 18.7 2800 14.4
9/16 750 5.1 620 2.8 1000 19.3 3000 26.0 14.0 1120 4.9 980 4.3 798 3.4 1540 3.5 1260 12.2 3220 18.7 2380 14.4
5/8 650 5.1 540 2.8 920 19.3 2700 22.4 16.0 980 5.5 840 4.7 700 4.1 1400 4.1 1120 12.4 2800 18.7 2100 14.4
11/16 580 5.1 480 2.8 810 19.3 2400 22.4 20.0 770 5.5 672 4.7 560 4.1 1120 4.3 900 13.2 2240 18.7 1680 14.4
13/16 500 5.1 430 2.8 730 17.3 2100 22.4
D
0.3D

0.7D D
※The FEED, in long & extra long types, should be reduced by around 50% RPM = rev./min. FEED = inch/min.
※ The Feed, in long & extra long types, should be reduced by around 50%. RPM = rev./min. FEED = inch/min.

CARBIDE, 4 FLUTE BALL NOSE TiAlN “F” COATED CARBIDE, 4 FLUTE TiAlN-COATED - SIDE CUTTING

EH250, EH060, EH062, EH252 SERIES EH540 SERIES
P K N P M K N
MATERIAL CARBON STEELS CARBON STEELS MATERIAL CARBON STEELS CARBON STEELS CARBON STEELS STAINLESS ALUMINUM COPPER. BRASS
ALLOY STEELS ALLOY STEELS CAST IRON ALUMINUM ALLOYS ALLOY STEELS ALLOY STEELS ALLOY STEELS STEELS CAST IRON ALLOYS NON-FERROUS
TOOL STEELS TOOL STEELS TOOL STEELS TOOL STEELS TOOL STEELS TITANIUM ALLOYS METALS
HARDNESS ~ HRc30 HRc30 ~ HRc40 HARDNESS ~ HRc 20 HRc 20 ~ HRc 30 HRc 30 ~ HRc 40
STRENGTH ~ 1000N/mm 2 1000 ~ 1300N/mm 2 STRENGTH 500 ~ 800N/mm 2 800 ~ 1000N/mm 2 1000 ~ 1300N/mm 2
DIAMETER RPM FEED RPM FEED RPM FEED RPM FEED DIAMETER RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED RPM FEED
3/32 8110 8.5 6840 4.3 11400 14.2 33600 26.0 2.0 7700 13.2 6720 11.6 5600 8.9 11200 11.0 9100 24.8 22400 53.0 16800 39.8
1/8 5400 9.4 4560 4.3 7680 14.6 22320 26.0 3.0 5180 15.0 4480 13.2 3640 9.8 7420 11.0 5880 24.8 15400 53.0 11200 39.8
5/32 4080 9.4 3240 4.3 5640 18.4 16800 26.0 4.0 3920 15.0 3360 13.2 2800 9.8 5600 11.0 4480 24.8 11200 53.0 8400 39.8
3/16 3240 9.9 2640 4.3 4560 21.3 13200 30.7 5.0 3080 15.0 2660 13.2 2240 9.8 4480 11.0 3500 24.8 8960 53.0 6720 39.8
1/4 2640 9.4 2270 4.3 3720 23.2 11280 30.7 6.0 2520 15.0 2240 13.2 1820 9.8 3640 11.0 2940 29.7 7420 56.3 5600 42.9
5/16 1920 8.5 1680 4.3 2760 29.3 8640 35.0 8.0 1960 15.0 1680 13.2 1400 9.8 2800 11.0 2240 31.5 5600 56.3 4200 42.9
3/8 1560 8.5 1320 4.3 2270 29.3 6720 35.0 10.0 1540 15.0 1330 13.2 1120 9.8 2240 11.0 1820 33.1 4480 56.3 3360 42.9
1/2 1320 8.0 1140 4.3 1920 29.3 5640 40.6 12.0 1260 15.0 1120 13.2 920 9.8 1820 11.0 1400 34.7 3640 56.3 2800 42.9
9/16 1180 8.0 960 4.3 1560 30.2 4680 40.6 14.0 1120 15.0 980 13.2 800 9.8 1540 11.0 1260 36.4 3220 56.3 2380 42.9
5/8 1020 8.0 840 4.3 1440 30.2 4200 35.0 16.0 980 16.5 840 14.4 700 12.2 1400 12.4 1120 37.4 2800 56.3 2100 42.9
11/16 900 8.0 740 4.3 1200 30.2 3720 35.0 20.0 770 16.5 670 14.4 560 12.2 1120 13.2 900 39.8 2240 56.3 1680 42.9
13/16 780 8.0 670 4.3 1140 26.9 3240 35.0
1.5D
0.3D
0.1D
0.7D
※ The Feed, in long & extra long types, should be reduced by around 50%. RPM = rev./min. FEED = inch/min. ※The FEED, in long & extra long types, should be reduced by around 50% RPM = rev./min. FEED = inch/min.
