CARBIDE
END MILLS RECOMMENDED CUTTING CONDITIONS
HSS Being the best through innovation
PROPERTIES AND APPLICATIONS OF COATINGS
Titanium Titanium Super TiAlN “F” Super TiAlN “E”
Nitride Carbonitride Coatings Coatings
Hardness 82 Rc 92 Rc 92 Rc 95 Rc
Coefficient of
Friction Against .4 .4 .4 .4
Dry Steel (.8)
Coating Thickness
3 Microns = .0001 1- 4 1- 4 1- 5 1- 3
Maximum Working
Temperature 1100 F 750 F 1470 F 1470 F
Coating Color Gold Blue - Gray Violet - Gray Violet - Gray
Key Good General Good Wear Enhanced High Hardness
Characteristics Purpose Resistance Toughness Enhanced
Good Toughness High Heat Toughness
Moderate Heat Resistance High Heat
Resistance Resistance
Primary Machining of General Steel, Cast lron, Hardened
Applications Iron Based Machining of Stainless, Workpieces,
Materials Various Nickel Based Alloys, Steel, Cast lron,
Materials High Temp and Stainless,
Titanium Alloys, Nickel Based Alloys,
High Speed High Temp and
Machining Wet, Titanium Alloys,
YG:TYLON SUPER TiAlN COATED TOOLS Dry, or Semi Dry Machining Wet,
CAN BE RUN 20% - 50% FASTER THAN Condition Dry, or Semi Dry
TiN or TiCN ON MOST MATERIALS
Condition
ONLY ONE COATED
PM60 END MILLS
- Perfect solution to protect carbide chipping problems under vibrations
