COBALT & HSS E2053 SERIES 8% COBALT (M42) COBALT & HSS E2100 SERIES 8% COBALT (M42)
COBALT & HSS
COBALT & HSS
FLAT SHANK
FLAT SHANK
END MILLS E1053 SERIES HSS (M2) END MILLS E1100 SERIES HSS (M2)
END MILLS
END MILLS
FLAT SHANK
FLAT SHANK
HSSCo8 & HSS, 6 FLUTE REGULAR with COMBINATION 2˝ SHANK
HSSCo8 & HSS, 4 FLUTE REGULAR LENGTH DOUBLE CENTER CUTTING
CENTER CUTTING
▶ Series E2053 end mills are the double-end version of E2039 center cutting single-end tools. They are used for slotting, shallow pocketing, ▶ These are to be used for heavy hogging cuts in die-sinking, tape & tracer controlled milling and similar work.
tracer milling or die sinking and similar operation. The Heavy-Duty end mills are made with toughened Combination shank, heavy web construction, accurate machine-ground end-teeth notching
and a special surface treatment to reduce cutting-edge wear.

P.1283, 1288, 1292 P.1283, 1288, 1292
Unit : Inch Unit : Inch
EDP No. Mill Shank Length Overall EDP No. Mill Shank Length Overall
8% COBALT (M42) HSS (M2) Diameter Diameter of Cut Length 8% COBALT (M42) HSS (M2) Diameter Diameter of Cut Length
13319 13069 31/64 1/2 1 4-1/8 10481 10231 2 2 2 5-3/4
13321 13071 1/2 1/2 1 4-1/8 10485 10235 2 2 4 7-3/4
13330 13080 9/16 5/8 1-3/8 5 10487 10237 2 2 5 8-3/4
13337 13087 5/8 5/8 1-3/8 5 10489 10239 2 2 6 9-3/4
13350 13100 11/16 3/4 1-5/8 5-5/8 10491 10241 2 2 8 11-3/4
13359 13109 3/4 3/4 1-5/8 5-5/8 ■ The TiN coated, TiCN coated or TiAIN coated is available on your request.
13377 13127 13/16 7/8 1-7/8 6-1/8 ■ Coating Codes for Cobalt
13394 13144 7/8 7/8 1-7/8 6-1/8 Uncoated EDP NO. + CN(TiN), CC(TiCN), CF(TiAIN F), CE(TiAIN E), CH(Hardslick)
13426 13176 1 1 1-7/8 6-3/8 ■ Coating Codes for HSS
Uncoated EDP NO. + HN(TiN), HC(TiCN), HF(TiAIN F), HE(TiAIN E), HH(Hardslick)
■ The TiN coated, TiCN coated or TiAIN coated is available on your request. ▶ Coated Price Shown in Price List. Call for Availability.
■ Coating Codes for Cobalt
Uncoated EDP NO. + CN(TiN), CC(TiCN), CF(TiAIN F), CE(TiAIN E), CH(Hardslick) Mill Dia.
■ Coating Codes for HSS Tolerance (inch)
Uncoated EDP NO. + HN(TiN), HC(TiCN), HF(TiAIN F), HE(TiAIN E), HH(Hardslick)
▶ Coated Price Shown in Price List. Call for Availability. 0~+.0030

Mill Dia.
Tolerance (inch)
0~—.0010 0~—.0020
The shank of end mills is the same diameter as the cutting portion.

◎ : Excellent ◯ : Good ◎ : Excellent ◯ : Good
P H M K N S P H M K N S
Carbon Alloy Prehardened Hardened Steels High Hardened High Carbon Alloy Prehardened High Hardened High
Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature Steels Steels Steels Hardened Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
Steels
Iron
~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy ~HRc20 HRc20~30 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Steels Iron Alloy
◎ ◎ ○ ○ ○ ◎ ◎ ○ ○
