STRAIGHT DL517 SERIES UN-COATED STRAIGHT
SHANK DRILLS DX517 SERIES TiCN-COATED SHANK DRILLS D4107 SERIES

HSSCo5, STRAIGHT SHANK PARABOLIC FLUTE TAPER LENGTH HSSCo8, STRAIGHT SHANK DRILL STUB

▶Flute Geometry : Right hand spiral, Parabolic flute ▶Flute Geometry : Right hand spiral helix
38° helix ▶Point Angle : 135˚
▶Point Angle : 130° : Split point under 1.6mm : Normal point
▶Application : Improved chip removal in most materials, especially in deep drilling applications. 1.6mm & over : Split point
▶Surface Treatment : TiN Coating
▶Application : Drills suitable for drilling in thin materials with portable drills. Special twist drills for automatic and turret lathes.

D1 D1
L1
L1
L2 under 1.6mm 1.6mm & over
L2

HSS-E
130 P.234 135 P.235
▶ Fractional sizes Unit : Inch Unit : mm
Diameter Flute Overall Diameter Flute Overall Diameter Flute Overall
EDP No. EDP No. EDP No.
Fractional Decimal Length Length Metric Inch Length Length Metric Inch Length Length
UN-COATED TiCN-COATED D1 L1 L2 TiN D1 L1 L2 TiN L1 L2
* DL517005 DX517005 5/64 .0781 2 3-3/4 * D4107010 1.0 .0394 6 26 ** D4107035 3.5 .1378 20 52
* DL517006 DX517006 3/32 .0938 2-1/4 4-1/4 * D4107011 1.1 .0433 7 28 ** D4107036 3.6 .1417 20 52
* DL517007 DX517007 7/64 .1094 2-1/2 4-5/8 * D4107012 1.2 .0472 8 30 ** D4107037 3.7 .1457 20 52
* DL517008 DX517008 1/8 .1250 2-3/4 5-1/8 * D4107912 1.25 .0492 8 30 ** D4107937 3.75 .1476 20 52
* DL517009 DX517009 9/64 .1406 3 5-3/8 * D4107013 1.3 .0512 8 30 ** D4107038 3.8 .1496 22 55
* DL517010 DX517010 5/32 .1563 3 5-3/8 * D4107014 1.4 .0551 9 32 ** D4107039 3.9 .1535 22 55
9
* DL517011 DX517011 11/64 .1719 3-3/8 5-3/4 * D4107015 1.5 .0591 10 32 ** D4107040 4.0 .1575 22 55
.1614
D4107016
55
22
.0630
1.6
34
D4107041
4.1
**
*
* DL517012 DX517012 3/16 .1875 3-3/8 5-3/4 * D4107017 1.7 .0669 10 34 ** D4107042 4.2 .1654 22 55
* DL517013 DX517013 13/64 .2031 3-5/8 6 * D4107917 1.75 .0689 11 36 ** D4107942 4.25 .1673 22 55
* DL517014 DX517014 7/32 .2188 3-5/8 6 * D4107018 1.8 .0709 11 36 ** D4107043 4.3 .1693 24 58
* DL517015 DX517015 15/64 .2344 3-3/4 6-1/8 * D4107019 1.9 .0748 11 36 ** D4107044 4.4 .1732 24 58
** DL517016 DX517016 1/4 .2500 3-3/4 6-1/8 * D4107020 2.0 .0787 12 38 ** D4107045 4.5 .1772 24 58
** DL517017 DX517017 17/64 .2656 3-7/8 6-1/4 * D4107021 2.1 .0827 12 38 ** D4107046 4.6 .1811 24 58
** DL517018 DX517018 9/32 .2813 3-7/8 6-1/4 * D4107022 2.2 .0866 13 40 ** D4107946 4.65 .1831 24 58
** DL517019 DX517019 19/64 .2969 4 6-3/8 * D4107925 2.25 0.886 13 40 ** D4107047 4.7 .1850 24 58
** DL517020 DX517020 5/16 .3125 4 6-3/8 * D4107023 2.3 .0906 13 40 ** D4107947 4.75 .1870 24 58
** DL517021 DX517021 21/64 .3281 4-1/8 6-1/2 * D4107024 2.4 .0945 14 43 ** D4107048 4.8 .1890 26 62
** DL517022 DX517022 11/32 .3438 4-1/8 6-3/4 * D4107025 2.5 .0984 14 43 ** D4107049 4.9 .1929 26 62
26
D4107026
5.0
D4107050
43
14
2.6
.1024
.1969
62
** DL517023 DX517023 23/64 .3594 4-1/4 6-3/4 * D4107027 2.7 .1063 16 46 ** D4107051 5.1 .2008 26 62
**
*
** DL517024 DX517024 3/8 .3750 4-1/4 6-3/4 ** D4107927 2.75 .1083 16 46 ** D4107052 5.2 .2047 26 62
** DL517025 DX517025 25/64 .3906 4-3/8 7 ** D4107028 2.8 .1102 16 46 ** D4107952 5.25 .2067 26 62
** DL517026 DX517026 13/32 .4063 4-3/8 7 ** D4107029 2.9 .1142 16 46 ** D4107053 5.3 .2087 26 62
** DL517027 DX517027 27/64 .4219 4-5/8 7-1/4 ** D4107030 3.0 .1181 16 46 ** D4107054 5.4 .2126 28 66
** DL517028 DX517028 7/16 .4375 4-5/8 7-1/4 ** D4107031 3.1 .1220 18 49 ** D4107055 5.5 .2165 28 66
** DL517029 DX517029 29/64 .4531 4-3/4 7-1/2 ** D4107032 3.2 .1260 18 49 ** D4107955 5.55 .2185 28 66
** DL517030 DX517030 15/32 .4688 4-3/4 7-1/2 ** D4107932 3.25 .1280 18 49 ** D4107056 5.6 .2205 28 66
** DL517031 DX517031 31/64 .4844 4-3/4 7-3/4 ** D4107033 3.3 .1299 18 49 ** D4107057 5.7 .2244 28 66
** DL517032 DX517032 1/2 .5000 4-3/4 7-3/4 ** D4107034 3.4 .1339 20 52 ** D4107957 5.75 .2264 28 66
▶ Tolerance : See page 218 * 10pcs per package ** 5pcs per package ▶ The HSSCo5(DL107) is available when you need. * 10pcs per package ** 5pcs per package
The TiN(D4107), TiCN(D7107) and TiAlN(DQ107) are available on your request.
