STRAIGHT DL517 SERIES UN-COATED STRAIGHT
SHANK DRILLS DX517 SERIES TiCN-COATED SHANK DRILLS D4107 SERIES

HSSCo5, STRAIGHT SHANK PARABOLIC FLUTE TAPER LENGTH HSSCo8, STRAIGHT SHANK DRILL STUB

▶Flute Geometry : Right hand spiral, Parabolic flute ▶Flute Geometry : Right hand spiral helix
38° helix ▶Point Angle : 135˚
▶Point Angle : 130° : Split point under 1.6mm : Normal point
▶Application : Improved chip removal in most materials, especially in deep drilling applications. 1.6mm & over : Split point
▶Surface Treatment : TiN Coating
▶Application : Drills suitable for drilling in thin materials with portable drills. Special twist drills for automatic and turret lathes.

D1 D1
L1
L1
L2 under 1.6mm 1.6mm & over
L2

HSS-E
130 P.234 135 P.235
▶ Fractional sizes Unit : Inch Unit : mm
Diameter Flute Overall Diameter Flute Overall Diameter Flute Overall
EDP No. EDP No. EDP No.
Fractional Decimal Length Length Metric Inch Length Length Metric Inch Length Length
UN-COATED TiCN-COATED D1 L1 L2 TiN D1 L1 L2 TiN L1 L2
* DL517005 DX517005 5/64 .0781 2 3-3/4 * D4107010 1.0 .0394 6 26 ** D4107035 3.5 .1378 20 52
* DL517006 DX517006 3/32 .0938 2-1/4 4-1/4 * D4107011 1.1 .0433 7 28 ** D4107036 3.6 .1417 20 52
* DL517007 DX517007 7/64 .1094 2-1/2 4-5/8 * D4107012 1.2 .0472 8 30 ** D4107037 3.7 .1457 20 52
* DL517008 DX517008 1/8 .1250 2-3/4 5-1/8 * D4107912 1.25 .0492 8 30 ** D4107937 3.75 .1476 20 52
* DL517009 DX517009 9/64 .1406 3 5-3/8 * D4107013 1.3 .0512 8 30 ** D4107038 3.8 .1496 22 55
* DL517010 DX517010 5/32 .1563 3 5-3/8 * D4107014 1.4 .0551 9 32 ** D4107039 3.9 .1535 22 55
9
* DL517011 DX517011 11/64 .1719 3-3/8 5-3/4 * D4107015 1.5 .0591 10 32 ** D4107040 4.0 .1575 22 55
.1614
55
D4107016
34
22
1.6
4.1
.0630
D4107041
*
**
* DL517012 DX517012 3/16 .1875 3-3/8 5-3/4 * D4107017 1.7 .0669 10 34 ** D4107042 4.2 .1654 22 55
* DL517013 DX517013 13/64 .2031 3-5/8 6 * D4107917 1.75 .0689 11 36 ** D4107942 4.25 .1673 22 55
* DL517014 DX517014 7/32 .2188 3-5/8 6 * D4107018 1.8 .0709 11 36 ** D4107043 4.3 .1693 24 58
* DL517015 DX517015 15/64 .2344 3-3/4 6-1/8 * D4107019 1.9 .0748 11 36 ** D4107044 4.4 .1732 24 58
** DL517016 DX517016 1/4 .2500 3-3/4 6-1/8 * D4107020 2.0 .0787 12 38 ** D4107045 4.5 .1772 24 58
** DL517017 DX517017 17/64 .2656 3-7/8 6-1/4 * D4107021 2.1 .0827 12 38 ** D4107046 4.6 .1811 24 58
** DL517018 DX517018 9/32 .2813 3-7/8 6-1/4 * D4107022 2.2 .0866 13 40 ** D4107946 4.65 .1831 24 58
** DL517019 DX517019 19/64 .2969 4 6-3/8 * D4107925 2.25 0.886 13 40 ** D4107047 4.7 .1850 24 58
** DL517020 DX517020 5/16 .3125 4 6-3/8 * D4107023 2.3 .0906 13 40 ** D4107947 4.75 .1870 24 58
** DL517021 DX517021 21/64 .3281 4-1/8 6-1/2 * D4107024 2.4 .0945 14 43 ** D4107048 4.8 .1890 26 62
** DL517022 DX517022 11/32 .3438 4-1/8 6-3/4 * D4107025 2.5 .0984 14 43 ** D4107049 4.9 .1929 26 62
26
D4107026
5.0
D4107050
43
14
2.6
.1024
.1969
62
** DL517023 DX517023 23/64 .3594 4-1/4 6-3/4 * D4107027 2.7 .1063 16 46 ** D4107051 5.1 .2008 26 62
**
*
** DL517024 DX517024 3/8 .3750 4-1/4 6-3/4 ** D4107927 2.75 .1083 16 46 ** D4107052 5.2 .2047 26 62
** DL517025 DX517025 25/64 .3906 4-3/8 7 ** D4107028 2.8 .1102 16 46 ** D4107952 5.25 .2067 26 62
** DL517026 DX517026 13/32 .4063 4-3/8 7 ** D4107029 2.9 .1142 16 46 ** D4107053 5.3 .2087 26 62
** DL517027 DX517027 27/64 .4219 4-5/8 7-1/4 ** D4107030 3.0 .1181 16 46 ** D4107054 5.4 .2126 28 66
** DL517028 DX517028 7/16 .4375 4-5/8 7-1/4 ** D4107031 3.1 .1220 18 49 ** D4107055 5.5 .2165 28 66
** DL517029 DX517029 29/64 .4531 4-3/4 7-1/2 ** D4107032 3.2 .1260 18 49 ** D4107955 5.55 .2185 28 66
** DL517030 DX517030 15/32 .4688 4-3/4 7-1/2 ** D4107932 3.25 .1280 18 49 ** D4107056 5.6 .2205 28 66
** DL517031 DX517031 31/64 .4844 4-3/4 7-3/4 ** D4107033 3.3 .1299 18 49 ** D4107057 5.7 .2244 28 66
** DL517032 DX517032 1/2 .5000 4-3/4 7-3/4 ** D4107034 3.4 .1339 20 52 ** D4107957 5.75 .2264 28 66
▶ Tolerance : See page 218 * 10pcs per package ** 5pcs per package ▶ The HSSCo5(DL107) is available when you need. * 10pcs per package ** 5pcs per package
The TiN(D4107), TiCN(D7107) and TiAlN(DQ107) are available on your request.
◎ : Excellent ◯ : Good ◎ : Excellent ◯ : Good
P H M K N S P H M K N S
Carbon Prehardened Carbon Prehardened
Steels Alloy Steels Steels Hardened Steels Stainless Cast Iron Aluminum Copper Bronze CFRP Titanium Steels Alloy Steels Steels Hardened Steels Stainless Cast Iron Aluminum Copper Bronze CFRP Titanium
Steels
~HB225 HB225~325 HRc30~45 HRc45~55 HRc55~ ~HB225 HB225~325 HRc30~45 HRc45~55 HRc55~ Steels
◎ ◎ ○ ◎ ◎ ○ ○ ○ ○
