MILLING TOOLS APPLICATION TABLE SOLID

◎ : Excellent ◯ : Good
P H M K N S
High
SIZE RANGE Carbon Alloy Prehardened Hardened Steels Hardened High
ITEM MODEL FLUTES HELIX INCH / TYPE PAGE Steels Steels Steels Steels Stainless Cast Copper Graphite Aluminum Acrylic CFRP Titanium Temperature
METRIC Steels Iron
MIN MAX ~HB225 HB225~325 HRc30~40 HRc40~45 HRc45~55 HRc55~70 Alloy
EM097 4Flute 30° Inch Long Ball R1/16 R5/16 878 ○ ◎ ◎ ◎ ○ ○ ○

EM666 3~5Flute 20° Inch Stub Roughing D1/4 D1 879 ○ ◎ ◎ ◎ ○ ○ ○

EM156 3~5Flute 20° Inch Long Roughing D1/4 D1 879 ○ ◎ ◎ ◎ ○ ○ ○
EM662 3~5Flute 20° Inch Long Roughing Ball R1/8 R1/2 880 ○ ◎ ◎ ◎ ○ ○

EM966 2Flute 30° Inch Rib D1/32 D1/8 881 ○ ◎ ◎ ◎ ○ ○

EM967 2Flute 30° Inch Ball for Rib R1/64 R1/16 882 ○ ◎ ◎ ◎ ○ ○

EM810 2Flute 30° Metric Short D1.0 D25.0 883 ○ ◎ ◎ ◎ ○ ○ ○

EM816 2Flute 30° Metric Long D2.0 D25.0 884 ○ ◎ ◎ ◎ ○ ○ ○

EM811 4Flute 30° Metric Short D2.0 D25.0 885 ○ ◎ ◎ ◎ ○ ○ ○

EM817 4Flute 30° Metric Long D2.0 D25.0 886 ○ ◎ ◎ ◎ ○ ○
EM895 3Flute 38° Metric Short D1.0 D20.0 887 ○ ◎ ◎ ◎ ○ ○ ○

EM810 2Flute 30° Metric Miniature D0.4 D1.5 888 ○ ◎ ◎ ◎ ○ ○

EM818 2Flute 30° Metric Long Radius D3.0 D20.0 889 ○ ◎ ◎ ◎ ○

EM819 4Flute 30° Metric Long Radius D3.0 D20.0 889 ○ ◎ ◎ ◎ ○ ○ ○
X-POWER
EM905 4Flute 45° Metric Short Radius D10.0 D22.0 890 ○ ◎ ◎ ◎ ○ ○ ○
EM839 4Flute 30° Metric Stub Radius D2.0 D16.0 891 ○ ◎ ◎ ◎ ○ ○

EM812 6&8Flute 45° Metric Long D6.0 D25.0 892 ○ ◎ ◎ ◎ ○ ○

EM834 6&8Flute 45° Metric Extra Long D6.0 D25.0 892 ○ ◎ ◎ ◎ ○ ○

EM835 6Flute 45° Metric Long Radius D6.0 D20.0 893 ○ ◎ ◎ ◎ ○ ○

EM897 6Flute 45° Metric Stub Radius D6.0 D12.0 894 ○ ◎ ◎ ◎ ○ ○

EM876 2Flute 30° Metric Long Ball R0.5 R12.5 895 ○ ◎ ◎ ◎ ○ ○ ○
EM813 2Flute 30° Metric Long Ball R0.5 R12.5 896 ○ ◎ ◎ ◎ ○ ○ ○
EM823
EM815 4Flute 30° Metric Long Ball R0.5 R12.5 896 ○ ◎ ◎ ◎ ○ ○ ○
EM825
EM899 2Flute 30° Metric Medium Ball R1.5 R12.5 897 ○ ◎ ◎ ◎ ○ ○ ○

EM838 2Flute 30° Metric Long Reach Ball R1.0 R10.0 898 ○ ◎ ◎ ◎ ○ ○ ○

EM865 2Flute 30° Metric Miniature Ball R0.3 R0.75 899 ○ ◎ ◎ ◎ ○ ○

EM868 2Flute 15° Metric Stub Ball R0.5 R12.5 900 ○ ◎ ◎
EM902 2Flute 30° Metric Ball with Taper Neck R0.5 R6.0 901 ○ ○ ◎ ◎ ○
