LATCH-ACTION TOGGLE CLAMPS

Sizes marked * are also available in
stainless steel

All Carr Lane Manufacturing toggle clamps are DFARS and RoHS compliant.

Adjustable U Bolt
pp. 516-519
Latch-action clamp with a threaded U bolt
for adjustability. Supplied with matching
latch plate (smallest three sizes). Large,
comfortable handle grip. Available in five
sizes.
360 lbs* 700 lbs* 2000 lbs* 4000 lbs 7500 lbs

Right-Angle Adjustable U Bolt
p. 520
Similar to the latch clamp above, except
with its pulling direction perpendicular to
the base. Supplied with matching latch
plate. Large, comfortable handle grip.
Available in three sizes.
500 lbs* 1000 lbs* 2000 lbs*

Adjustable Hook
p. 515
11
Popular hook-type latch clamp. Hook is
threaded at one end for easy adjustment.
Base rotates 90° to allow horizontal or
vertical latching. Available in two sizes.
375 lbs* 1000 lbs

Fixed Length
p. 521
Latch clamp with fixed reach for
installation where no length adjustment is
required. Adjustable stop allows latching
at different heights. Available in two sizes.
375 lbs* 1200 lbs
