Page 736 - CarrLaneCatalog_2019ed-c.pdf

Fittings J Metric J F9.300

Fitting accessories with 24° cone as per DIN EN ISO 8434-1
J
plug-type connectors hydraulic pipes pipe clamps
J
J

• Worldwide spread high-pressure fitting Tube male stud coupling with cutting ring
system with quadruple safety and union nut
• Leak-free connection of piping and Before tightening After tightening
components
• Positive and safe connection by defined
and limited digging into the hydraulic
pipe
• Retightening of the union nut is not
required
• The fitting can be disconnected and
connected again as often as required.

Screwed plug with knife edge
Suitable for high temperatures
and aggressive media.
DIN 3852 T2 form B and
Application example EN ISO 1179-4

Pressure gauge
0-40 bar
0-100 bar Screwed plug with elastic sealing
0-250 bar
0-400 bar DIN 3852 T11 form E and EN ISO 1179-2
0-600 bar NBR: – 35°C…….+ 100°C (series)
FKM: – 25°C…….+ 200°C (available)
Pressure gauge union
Pressure gauge union
Tube male stud coupling
Swivel banjo coupling
T-coupling
Cross-type coupling
T-swivel coupling
Swivel banjo coupling
Stand pipe union Suitable for soft mating materials (Alu).
90° elbow coupling High precision sealing (no sweating).
Straight coupling
Double connector No retightening required.
Plug Unlimited repeated mounting.
G 1/4
Hydraulic pipe EN 10305-1, Interchangeable sealing ring.
galvanized
Pipe clamps - see page 737
Tapped hole
Quick-disconnect coupling
see page 728 with Whitworth pipe thread
Nipple
G 1/4 EN ISO 1179-1 counterbore form N
Coupler
High-pressure hoses ND 6 A Ø D
G 1/4
Length: 500 mm 0,1
1000 mm 90°
1600 mm G
2500 mm Ra 3,2 A A
see page 728 c
B
min. 100 mm
14
Subject to change. For further details, including detailed dimensions and mounting instructions, visit roemheld-usa.com.
