Accessories

Fixture Hose

Standard Hose
Small-Diameter high-pressure hose perfect for workholding
applications. Abrasion and chemical resistant outer cover
with seamless nylon inner sleeve reinforced with synthetic
yarn. Other lengths and diameters available upon request.
Standard Hose with Nominal ID 0.156 in
Stainless Steel Armor Casing* Nominal OD 0.34 in
Min. bend radius 1.6 in
Burst pressure 25,520 psi
Temperature range -40 to +150°F

End Type
For stainless steel armor casing add “A” Length
at the end of the part number. #5 JIC
Example: CLR-HH-156-016-5J5JA Part No., 9 inch CLR-HH-156-009-5J5J
*Only available in 16 inch lengths and up. Part No., 12 inch CLR-HH-156-012-5J5J
Part No., 15 inch CLR-HH-156-015-5J5J
Part No., 18 inch CLR-HH-156-018-5J5J
Part No., 24 inch CLR-HH-156-024-5J5J

Tubing Heavy-Duty Hose Hydraulic Fluid

Steel Tubing High-pressure hydraulic hose. 1/4” inside Roemheld Hydraulic oils are compounded
Seamless heavy-wall tubing. C1010 diameter. Reinforced with four plies of high- from premium, paraffinic base oils, plus a
steel, cold drawn, fully annealed 1/4”, tensile wire, for remarkably little expansion thermally stable zinc additive system that
5/16” and 3/8” OD available. Do not use under pressure. Fluid required due to expansion affords improved anti-wear and hydrolytic
any other type of tubing. See next page is only .066 cu. in. per foot at 7500 psi. 5” stability while maintaining superior
for installation guidelines and tools minimum bend radius. Two female ends, 5/16 oxidation stability. Use only ROEMHELD
(CLR-300-TL flaring tool is strongly JIC 37° flare, or straight tube ends for use with oil or an exact equivalent. FLUID MUST
recommended). compression fittings. BE CLEAN (10 micron or better nominal
filtration) See also high pressure in-line
NOTE! 10’-0” MAXIMUM
RECOMMENDED LENGTH filters.
Wall JIC 37° flare Compression Type
Part No. O.D. Length* 18” CLR-18-H CLR-18-H-CC Part No. ISO GRADE Container Size
Thickness
CLR-TC-2500-049-060 1/4” 0.049” 60” 24” CLR-24-H CLR-24-H-CC CLR-22-FL 22 1 gal.
30” CLR-30-H CLR-30-H-CC
CLR-TC-3125-065-060 5/16” 0.065” 60” CLR-32-FL 32 1 gal.
36” CLR-36-H CLR-36-H-CC
CLR-TC-3750-065-060 3/8” 0.065” 60” CLR-46-FL 46 1 gal.
42” CLR-42-H CLR-42-H-CC
48” CLR-48-H CLR-48-H-CC
*Custom lengths available on request
14
60” CLR-60-H CLR-60-H-CC
72” CLR-72-H CLR-72-H-CC
(Special lengths available)
