Page 151 - 75th-Online-Anniversary-Catalog

DRILLS

1510

Cutting Diameter Flute Shank Overall EDP Number
Length Diameter Length UC
.1094 7/64 5/8 .1094 2 16033
.1100 35 5/8 .1100 2 16034
.1110 34 5/8 .1110 2 16035
.1130 33 5/8 .1130 2 15277
.1160 32 5/8 .1160 2 16036
.1200 31 5/8 .1200 2 16038
.1250 1/8 5/8 .1250 2 15201
.1285 30 5/8 .1285 2 16039
.1360 29 5/8 .1360 2 15278
.1405 28 5/8 .1405 2 16041
.1406 9/64 5/8 .1406 2 15202
.1440 27 3/4 .1440 2 1/2 16042
.1470 26 3/4 .1470 2 1/2 16043
.1495 25 3/4 .1495 2 1/2 15279
.1520 24 3/4 .1520 2 1/2 16044
.1540 23 3/4 .1540 2 1/2 16045
.1562 5/32 3/4 .1562 2 1/2 15203
.1570 22 3/4 .1570 2 1/2 15280
.1590 21 3/4 .1590 2 1/2 16047
.1610 20 3/4 .1610 2 1/2 16048
.1660 19 3/4 .1660 2 1/2 16049
.1695 18 3/4 .1695 2 1/2 16050
.1719 11/64 3/4 .1719 2 1/2 15204
.1730 17 3/4 .1730 2 1/2 16051
.1770 16 3/4 .1770 2 1/2 16052
.1800 15 3/4 .1800 2 1/2 16054
.1820 14 3/4 .1820 2 1/2 16055
.1850 13 3/4 .1850 2 1/2 16056
.1875 3/16 3/4 .1875 2 1/2 15205
.1890 12 3/4 .1890 2 1/2 16057
.1910 11 3/4 .1910 2 1/2 16058
.1935 10 3/4 .1935 2 1/2 16059
.1960 9 3/4 .1960 2 1/2 16060
.1990 8 3/4 .1990 2 1/2 16062
.2010 7 3/4 .2010 2 1/2 16063
.2031 13/64 3/4 .2031 2 1/2 15206 UNCOATED
.2040 6 1 .2040 2 1/2 16064
.2055 5 1 .2055 2 1/2 16065 I M
.2090 4 1 .2090 2 1/2 16066
.2130 3 1 .2130 2 1/2 15281 IMPERIAL METRIC
.2188 7/32 1 .2188 2 1/2 15207
.2210 2 1 .2210 2 1/2 16068
.2280 1 1 .2280 2 1/2 16069
.2340 A 1 .2340 2 1/2 16070
.2344 15/64 1 .2344 2 1/2 15208
.2380 B 1 .2380 2 1/2 16072
.2420 C 1 .2420 2 1/2 16073
.2460 D 1 .2460 2 1/2 16074
.2500 1/4 1 .2500 2 1/2 15209
.2570 F 1 .2570 2 1/2 15282
.2610 G 1 .2610 2 1/2 16076
.2656 17/64 1 .2656 2 1/2 15210
.2660 H 1 .2660 2 1/2 16078
■ Titanium ■ Hardened Steels ■ Stainless Steels ■ Steels ■ Cast Iron ■ Graphite ■ Brass & Copper ■ High Si Al
■ Low Si Al ■ Composites ■ Wood ■ General Purpose

Visit fullertontool.com for the most up to date information. 149
