DRILLS

1510

Cutting Diameter Flute Shank Overall EDP Number
Length Diameter Length UC
.2720 I 1 .2720 2 1/2 15283
.2770 J 1 .2770 2 1/2 16080
.2810 K 1 .2810 2 1/2 16081
.2812 9/32 1 .2812 2 1/2 15211
.2900 L 1 1/4 .2900 2 3/4 16082
.2950 M 1 1/4 .2950 2 3/4 16083
.2969 19/64 1 1/4 .2969 2 3/4 15212
.3020 N 1 1/4 .3020 2 3/4 16085
.3125 5/16 1 1/4 .3125 2 3/4 15213
.3160 O 1 1/4 .3160 2 3/4 16087
.3230 P 1 1/4 .3230 2 3/4 16088
.3281 21/64 1 1/4 .3281 2 3/4 15214
.3320 Q 1 1/4 .3320 3 16089
.3390 R 1 1/4 .3390 3 16091
.3438 11/32 1 1/4 .3438 3 15215
.3480 S 1 1/4 .3480 3 16092
.3580 T 1 1/4 .3580 3 16094
.3594 23/64 1 1/4 .3594 3 15216
.3680 U 1 1/4 .3680 3 16095
.3750 3/8 1 1/4 .3750 3 15217
.3770 V 1 1/4 .3770 3 16097
.3860 W 1 1/4 .3860 3 16098
.3906 25/64 1 1/4 .3906 3 15218
.3970 X 1 1/4 .3970 3 16100
.4040 Y 1 1/4 .4040 3 16101
.4062 13/32 1 1/4 .4062 3 15219
.4130 Z 1 1/4 .4130 3 16102
.4219 27/64 1 1/4 .4219 3 15220
UNCOATED .4375 7/16 1 1/4 .4375 3 15221
.4531 29/64 1 1/4 .4531 3 15222
I M .4688 15/32 1 1/4 .4688 3 15223
.4844 31/64 1 1/4 .4844 3 15224
IMPERIAL METRIC
.5000 1/2 1 1/4 .5000 3 15225
.5312 17/32 1 1/4 .5312 3 1/2 16108
.5625 9/16 1 1/2 .5625 3 1/2 15256
.5938 19/32 1 1/2 .5938 3 1/2 16109
.6250 5/8 1 1/2 .6250 3 1/2 15262
.6562 21/32 1 1/2 .6562 3 1/2 16110
.6875 11/16 1 1/2 .6875 4 16111
.7188 23/32 1 1/2 .7188 4 16112
.7500 3/4 1 1/2 .7500 4 15275
.8750 7/8 1 1/2 .8750 4 16113
1.0000 1 1 1/2 1.0000 4 16114
Standard Length
.0280 70 5/16 .0280 1 1/4 15012
■ Titanium ■ Hardened Steels ■ Stainless Steels ■ Steels ■ Cast Iron ■ Graphite ■ Brass & Copper ■ High Si Al
■ Low Si Al ■ Composites ■ Wood ■ General Purpose
