I N DUS T R I A L A U T O M A TI O N & P R O C E S S C O NTRO L C A B L E S 125

Technical Information
LSZH Jacketed Cables and Hazardous Locations Reference
Industrial Cable
Approvals and Standards/Performance Data Low-Smoke, Zero-Halogen
for Low-Smoke, Zero-Halogen Jacketed Cable Jacketed Cable Specifications
XLP Insulation
600V, 90°C TC-LC
Physical: (per UL-44) NEC 340/UL 1277 & 1685
Tensile (min) 1500 psi Deformation (max) 3.35
Instrumentation
Elongation (min) 150% LOI 27
• 18 to 12 AWG, BC or TC
Haloarrest ® HaloarrestXLink-1 HaloarrestXLink-2 • 90°C XLP insulation
Physical
• UL 44 XHHW-2 — 90°C dry/wet
Tensile (min) 1500 psi 1500 psi 1500 psi
• Shielded or unshielded
Elongation (min) 100% 150% 150%
®
Tear Resistance 74 lbs/inch — — • Haloarrest jacket
LOI 38 39 45
Control or Power
Halogen Content
IEC 754-1 0% 0% 0% • 14 to 4/0 AWG, BC or TC
BS6425 0% — — • 90°C XLP insulation
MIL-C-24643 <0.2% — —
• UL 44 XHHW-2 — 90°C dry/wet
NBS Smoke Chamber
• Shielded or unshielded
Flaming Mode 141 D corrected typical 164 D corrected typical —
m m
Smoldering Mode 311 D corrected typical 417 D corrected typical — • Haloarrest jacket
m m
Acid Gas
IEC 754-2 4.3 pH, 28 μS/cm 4.9 pH, 0.7 μS/cm <4.5 pH, 0.4 μS/cm
VDE 0472 Part 813 4.3 pH, 27 μS/cm — —
Toxicity Index
NES 713 1 4.6 —
EN50305-2 — — 2
Hazardous Locations Cable Reference

Article 500 Class II Division 1 Article 504
• Locations where combustible dusts exist
Class I Division 1 Hazards Intrinsically Safe
under normal conditions.
• Locations where flammable gases or • Equipment and wiring that are incapable
vapors may exist under normal operating • Use conduit or MI with approved of releasing sufficient electrical energy
termination fittings.
conditions, under frequent repair or under normal or abnormal conditions to
maintenance operations, or where break- cause ignition of a specific hazardous
down or faulty operation of process Class II Division 2 atmospheric mixture in its most easily
equipment might also cause simultaneous • Locations where combustible dusts exist ignited concentration.
failure of electrical equipment.
under abnormal conditions. • Use CL3, CL2, PLTC, TC or CM cable,
• Use conduit or MI cable with approved colored light blue, with approved sealing
termination fittings. • Use conduit or PLTC, ITC, TC, MC with and separation.
ventilated channel cable trays.
• Use conduit or MC, MI with approved Hazardous Location Cable
Class I Division 2 Hazards
termination fittings. Reference per Canadian
• Locations where flammable gases, vapors Electrical Code CEC Section 18
or volatile liquids are handled either Class III Division 1
in a closed system, or confined within All Armored cables printed “HL” per
suitable enclosures, or where hazardous • Locations where easily ignitable fibers and CSA C22.2 #174 are rated for all
concentrations are normally prevented flyings exist under normal conditions. Hazardous Location Classes and Divisions
by positive mechanical ventilation. Areas • Use conduit or MC, MI with approved (i.e., Class 1, Div. 1).
adjacent to Division 1 areas belong in
Division 2. termination fittings. All Tray Cables printed “TC” per CSA
C22.2 #230 are rated for all Hazardous
• Use PLTC, ITC, TC, MC, MV, MI with Class III Division 2
approved termination fittings. Location Classes and Division 2 or lower.
• Locations where easily ignitable fibers and (i.e., Class 1, Div. 2 or lower).
flyings exist under abnormal conditions.
• Use conduit or MC, MI with approved
termination fittings.
