MUL T I - COND UC T O R C A BL E S 160

Classic Multi-Conductor Cables

Belden’s Classic multi-conductor line includes a select number of Selection Guide
high-quality, high-reliability cables that meet or exceed UL standards
Shielded Multi-Conductor Computer Cables for RS-232 Applications
and have been used worldwide for decades.
Cable Series*
Specifications
Belden multi-conductor products deliver low voltage analog data 9925 9608 9533 9939
signals within enclosures, from controllers and I/Os to devices Conductor Size: 28
such as temperature and pressure sensors, relays, valves, meters, (AWG) 24
thermocouples, solenoids, actuators, contacts, push buttons, and 22
alarms. They also are applicable for computers, communications, Page No.: 177 174 174 176
instrumentation, sound, control, audio, data transmission, and
Insulation: S-R PVC
many more applications.
Datalene ®†
• Unsurpassed quality and reliability Shield: Overall Foil
• Robust designs that meet or exceed UL standards Drain Wire
Overall Foil/Braid
• Proven performance in installations worldwide
Braid Coverage 65% 65% 65%
• Broad range of AWG sizes, shielding options, and conductor counts
Drain Wire Overall: Yes No Yes No
• Convenient put-up options No. of Cond. Available: 3
• Polyolefin insulations provide lower capacitance performance 4
when compared to PVC insulated cables 5
6
Shielding
7
Belden meets the demand for highly effective shielding technology 8
with innovative, EMI/RFI-protective foil and braid designs like 9
Beldfoil®. Belden’s patented Beldfoil shield is an aluminum/polyester 10
foil construction that yields a lightweight, strong, flexible and thin 15
shield that provides extra insulation and 100% shield coverage. 20
Beldfoil is ideally suited for multiple-pair, individually shielded audio, 25
communication, and data cables. 30
37
Product Consistency
40
By manufacturing our products in ISO-certified, state-of-the-art 50
manufacturing facilities, Belden assures that quality is built into Capacitance** (pF/ft.) 12.0 30.0 30.0 35.0
each and every product. Precise diameter control of insulation and *All cables are UL-listed.
jacket diameters and concentric wall thickness assures fast, reliable **Capacitance may vary on some cables.
manufacturing in high-speed automated equipment, and ease of
termination and assembly in the field. Multi-Conductor Computer Cable
Overall Beldfoil Overall Foil/Braid
Find the Right Product for Your Application AWG
SR-PVC, PVC SR-PVC PE, PP
Belden Classic products are available from stock from Belden 26 (AMP SDL) — —
distributors. If the products above do not fit your application, 24 (RS-232) (RS-232) (RS-232/423)
Belden can also engineer specific constructions for your application. 22 — (RS-232) —

Audio, Control, Instrumentation and Other Multi-Conductor Cables
AWG Unshielded Overall Beldfoil Overall Foil/Braid Overall Braid
24 — — [ACI] [MIL-W-16878/4 (Type E)]
ACI ACI MIL-W-16878 (Type B)
22 [ACI] [Special Hi-Temp ACI] [ACI] [MIL-W-16878/4 (Type E)]
Fire Alarm
ACI ACI
ACI
20 ACI (Direct Burial) [ACI] MIL-W-16878 (Type B)
[Special Hi-Temp ACI]
[Special Hi-Temp ACI] [MIL-W-16878/4 (Type E)]
ACI ACI
18 [ACI] [ACI] [ACI] [MIL-W-16878/4 (Type E)]
CI, CIC, Fire Alarm CI, CIC, Fire Alarm
ACI ACI
[Special Hi-Temp ACI] [ACI] MIL-W-16878 (Type B)
16 [ACI]
CI, CIC, Fire Alarm [Special Hi-Temp ACI] [MIL-W-16878/4 (Type E)]
Rubber SO CI, CIC, Fire Alarm
ACI
14 CI, CIC, Fire Alarm [Fire Alarm] —
CI, CIC, Fire Alarm
12 CI, CIC, Fire Alarm CI, CIC, Fire Alarm [Fire Alarm] —
AIC = Audio, Control, and Instrumentation • CI = Circuit Integrity • CIC = Circuit Integrity in Conduit • [Brackets] = High-Temperature Cables.
