I N DUS T R I A L A U T O M A TI O N & P R O C E S S C O NTRO L C A B L E S 20

Industrial Data Solutions ®
®
DataTuff Industrial Ethernet Cordsets

Category 6 • Standard RJ45 Connectors
• 4-Pair Cable
• 23 AWG Solid BC Conductors
• Heavy-Duty Oil- & Sunlight-Resistant Black Jackets
• NEC: CMR, CMX-Outdoor • CEC: CMR FT4
• IP67 interface complies with the EtherNet/IP specification
(IEC 61076-3-106 Variant 1)

Part No.
Unshielded Shielded Length
Belden Bonded-Pair ™ Cable 7940A Belden Bonded-Pair Cable 7953A
IP67 (Tethered Cap) IP 20 (No Cap) IP67 (Tethered Cap) IP 20 (No Cap) Meters Feet
E600001 010S1 E601001 010S1 E604001 010S1 E605001 010S1 1 3.3
E600002 010S1 E601002 010S1 E604002 010S1 E605002 010S1 2 6.6
E600003 010S1 E601003 010S1 E604003 010S1 E605003 010S1 3 9.8
E600005 010S1 E601005 010S1 E604005 010S1 E605005 010S1 5 16.4
E600025 010S1 — E604025 010S1 — 25 82

Category 6 • Ruggedized Metal-Body RJ45 Connectors
• 4-Pair Cable
• 23 AWG Solid BC Conductors
• Heavy-Duty Oil- & Sunlight-Resistant Black Jackets
• NEC: CMR, CMX-Outdoor • CEC: CMR FT4

Part No.
Unshielded Shielded Length
Belden Bonded-Pair Cable 7940A Belden Bonded-Pair Cable 7953A
IP 20 (No Cap) IP 20 (No Cap) Meters Feet
R601001 010S1 R605001 010S1 1 3.3
R601002 010S1 R605002 010S1 2 6.6
R601003 010S1 R605003 010S1 3 9.8
R601005 010S1 R605005 010S1 5 16.4

BC = Bare Copper
