OUTSIDE EQUIPMENT
EEP/ESP
SERIE
EEP ESP
DIMENSIONS (mm) WEIGHT
CODE TREADS PACKING GROSS VOLUME
m3
A B C D E F G H I J K kg
7083 3 + 3 1090 1610 1050 360 390 230 260 500 500 710 – 1 20,0 0,090
7084 4 + 4 1250 1840 1280 360 390 230 260 500 500 710 – 1 21,5 0,070
7085 5 + 5 1410 2070 1510 360 390 230 260 500 500 710 – 1 24,8 0,079
7073 3 + 1 890 1610 1050 360 390 230 260 500 500 710 480 1 17,5 0,088
7074 4 + 1 970 1840 1280 360 390 230 260 500 500 710 480 1 18,7 –
7075 5 + 1 1050 2070 1510 360 390 230 260 500 500 710 480 1 19,8 –
MUNICH
SERIE
500 C
B
F
A
D
E
DIMENSIONS (mm) WEIGHT
CODE DESCRIPTION TREADS PACKING GROSS VOLUME
m3
A B C D E F kg
Ladder stainless steel serie Munich with
73221 anchor socket 2 stairs for public pools with 2 696 750 1000 260 207 500 1 11,0 –
overflow
Ladder stainless steel serie Munich with
73231 anchor socket 3 stairs for public pools with 3 946 750 1000 260 207 500 1 13,0 –
overflow
Ladder stainless steel serie Munich with
73241 anchor socket 4 stairs for public pools with 4 1196 750 1000 260 207 500 1 15,0 –
overflow
Ladder stainless steel serie Munich with
73251 anchor socket 5 stairs for public pools with 5 1446 750 1000 256 207 500 1 13,0 –
overflow
