SECTION 1.0 – GENERAL SECTION 1.0 – GENERAL

1.2.3 The successful tenderer shall undertake pre-computation surveys by a b) Experienced in designing and completed one (1) specialised health
licensed land surveyor to confirm the site boundaries. It shall be endorsed facility building or complex project (Category 1 of Architect Scale of
by Ketua Pengarah Tanah dan Galian (KPTG/PTG) for West Malaysia Minimum Fees, Rules 2010 or the latest edition published by LAM).
projects. As for projects in Sabah and Sarawak, references shall be made
to the respective local authority. The successful tenderer shall also c) The consultant shall have an experienced, adequate, and qualified team
undertake complete engineering surveys, indicating the existing of designers (minimum 1 Principal Architect, Project/Senior Architect,
topography, structures, vegetation, and relevant services within and and technical staff for producing drawings) and supervisory staff on-site,
outside the boundaries. including Resident Architect (minimum Part II LAM and Inspector of
Works registered with LAM).
1.2.4 The successful tenderer shall provide the site boundary demarcations and
all other boundaries separating the site’s zones. This exercise shall be d) Not more than one (1) design proposal submission is allowed by the
verified by KPTG/PTG or by the approving local authority. same consultant in the tender.

1.2.5 The successful tenderer shall complete engineering surveys inclusively 1.3.4 The tenderers shall appoint a Medical Planner and the engagement of the
indicating the existing topography, structures, vegetation, and services Medical Planner, preferably to fulfil the following requirements:
within and outside the boundaries (e.g., utility mapping) relevant to the
site’s development. a) Experienced in designing and completed two (2) hospital projects.

1.2.6 The successful tenderer shall verify with the approving local authority the b) Experienced and preferably qualified local Medical Planner with
planning guidelines of the proposed site. Planning guidelines such as plot- architectural qualification/background.
ratio, maximum height, usable plinth area, and other corresponding
guidelines shall be adhered to accordingly. 1.3.5 The tenderers shall also appoint other consultants as follows:

a) Medical Equipment Planner for preparation of Group 1, 2, 3 and 4
1.3 APPOINTMENT OF CONSULTANTS medical equipment listing as follows:

1.3.1 The tenderers shall appoint an Architect registered with the Ministry of Group 1 – Fixed equipment related to Mechanical & Electrical (supply &
Finance (MOF) and Lembaga Arkitek Malaysia (LAM) with experience in install by Contractor as per contract document).
the specific area as required by the Government. Copies of a valid
certificate of registration that indicates the name and registration date shall Group 2 – Fixed equipment related to Mechanical & Electrical (supply by
be included in the submission. Client and install by Contractor).

1.3.2 The consultant Architect’s appointment shall include the design, Group 3 – Loose equipment (equipment supply & install by Client).
supervision, and certification of works during the construction period and
the defects liability period described further in the government brief. The Group 4 – Loose and consumables items (Non-related to Mechanical &
consultant shall have an adequate and qualified design team and Electrical).
supervisory staff on site.
b) Town Planner.
1.3.3 The engagement of the Architect, preferably to fulfil the following
requirements: c) Interior Designer.

a) Experienced in designing and completed one (1) hospital project. d) Landscape Architect.

OR e) Other consultants that may be required by the Local Authority and/or
Government (e.g., Lab Specialist, Acoustic Specialist, Nuclear Medicine
/ Radiation Specialist etc.).

2 3
2021 EDITION HEALTH FACILITY ARCHITECTURAL NEEDS STATEMENT 2021 EDITION HEALTH FACILITY ARCHITECTURAL NEEDS STATEMENT
