Page 658 - Deko-Light Light Impressions 2019-20
P. 658
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 10 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
532551 450 - 630 nm 150 LEDs 36 W 850 lm / Stripe 170 lm / Meter EEI: A
24 SMD 120° 3 CH IP33 - 15°C M M
5050 + 50°C
Cutting option
over to 166 mm / 5 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 8 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
NANO Coating [Lotus effect]
Water rolls off and takes all dirty surface particles with it.
840263 450 - 630 nm 180 LEDs 42 W 1300 lm / Stripe 433 lm / Meter EEI: A
24 SMD - 15°C M M
5050 120° 3 CH IP44 + 50°C
Cutting option
over to 100 mm / 6 LED
LED-STRIPES | 3 Channel 657
