Page 657 - Deko-Light Light Impressions 2019-20
P. 657
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 10 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
840075 450 - 630 nm 90 LEDs 20 W 550 lm / Stripe 183 lm / Meter EEI: A
12 SMD - 15°C M M
5050 120° 3 CH IP33 + 50°C
Cutting option
over to 100 mm / 3 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 10 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
532351 450 - 630 nm 90 LEDs 21,6 W 550 lm / Stripe 183 lm / Meter EEI: A
24 SMD - 15°C M M
5050 120° 3 CH IP33 + 50°C
Cutting option
over to 166 mm / 5 LED
656 LED-STRIPES | 3 Channel
