Page 660 - Deko-Light Light Impressions 2019-20
P. 660
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 12 x 4 mm
LED rows: 1
Fixation: Incl. mounting set
Stripe connection: 4 cables [3x V-, V+]
840103 450 - 630 nm 150 LEDs 22 W 750 lm / Stripe 150 lm / Meter EEI: A
12 SMD - 15°C M M
5050 120° 3 CH IP67 + 50°C
Cutting option
over to 100 mm / 3 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 13 x 3 mm
LED rows: 1
Fixation: Incl. mounting set
Stripe connection: 4 cables [3x V-, V+]
840252 450 - 630 nm 300 LEDs 40 W 1400 lm / Stripe 280 lm / Meter EEI: A
12 SMD - 15°C M M
5050 120° 3 CH IP67 + 50°C
Cutting option
over to 50 mm / 3 LED
LED-STRIPES | 3 Channel 659
