Page 654 - Deko-Light Light Impressions 2019-20
P. 654
FLEXIBLE LED-STRIPE
Dim. L x W x H: 5000 x 10 x 2 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
840147 486 nm 480 LEDs 65 W 2600 lm / Stripe 520 lm / Meter EEI: A
24 SMD - 15°C M M
5050 120° 3 CH IP20 + 50°C
Cutting option
over to 62,5 mm / 6 LED
FLEXIBLE LED-STRIPE
Dim. L x W x H: 3000 x 10 x 3 mm
LED rows: 1
Fixation: Adhesive tape rear side
Stripe connection: 4 cables [3x V-, V+]
840257 450 - 630 nm 288 LEDs 60 W 2000 lm / Stripe 666 lm / Meter EEI: A
24 SMD - 15°C M M
5050 120° 3 CH IP20 + 50°C
Cutting option
over to 62,5 mm / 6 LED
LED-STRIPES | 3 Channel 653
