P. 680
LED MODULAR PANEL II 6 X 6
Dim. L x W x H: 240 x 240 x 3 mm
Material | Properties: Board
Fixation: Adhesive surface rear side
Module connection: Cable connection
Max. number in row: 3
Distance LED-centre : WW | NW | CW: 13,5 mm
Distance LED-centre : RGB: 27 mm
Cutting option 80 mm x 80 mm / 36 LEDs
inclusive: 1 x Cable connection
1 x Feed cable
10 x Connector
848009 3000 K 581 nm 324 LEDs 24 W 1564 lm / Panel EEI: A
848010 4000 K 580 nm 324 LEDs 24 W 1795 lm / Panel EEI: A
848011 6500 K 482 nm 324 LEDs 24 W 1651 lm / Panel EEI: A
848012 460 - 620 nm 162 LEDs 37 W 1306 lm / Panel EEI: B
24 SMD 120° IP20 - 15°C
3528 + 40°C
Accessories
930145 Feed cable Single color Modular Panel Flex L: 2000 mm
930147 Cable connection Single color Modular Panel Flex L: 1000 mm
930146 Feed cable RGB Modular Panel Flex L: 2000 mm
930248 Cable connection RGB Modular Panel Flex L: 1000 mm
930124 Power cable Single color Modular Panel L: 200 mm
930125 Power cable RGB Modular Panel L: 200 mm
848011 | CW 848012 | RGB
LED-MODULAR PANEL | 1 - 3 Channel 679
