Page 681 - Deko-Light Light Impressions 2019-20
P. 681
LED MODULAR SYSTEM | KW
Dim. L x W x H: 39 x 37 x 5,8 mm
Material: Plastic
Module pro VPE: 20
Fixation: Screw-connection, adhesive tape
Module connection: 2 cables (V+, V-)
Cutting option: according to each module
Cable length between module: ca. 135 mm
848000 6500 K [+/- 150 K] 80 LEDs 26 W 2100 lm / Panel EEI: A
12 SMD 120° IP65 - 20°C
2835 + 60°C
LED MODULAR SYSTEM | RGB
Dim. L x W x H: 37 x 41 x 5,7 mm
Material: Plastic
LED Color: RGB 3in1
Module pro VPE: 20
Fixation: Screw-connection, adhesive tape
Module connection: 4 cables (R,G,B,V+)
Cutting option: according to each module
Cable length between module: ca. 87 mm
848001 465 - 635 nm 60 LEDs 14 W 360 lm / Panel EEI: B
12 SMD - 20°C
5050 120° IP65 + 60°C
680 LED-MODULAR SYSTEM | 1 - 3 Channel
