P. 703
KAPEGO CONTROLLER TC-2 KAPEGO TOUCH 16CH PRO
The TC-2 controller is a touch panel, allowing the storage and The Touch 16CH Pro controller is a touch panel, allowing
retrieval of up to 4 storage locations. Scenes and atmosphe- the storage and retrieval of up to 4 zones with 4 channels
res are created quickly in a user-friendly manner with the aid each. Scenes and atmospheres are created quickly in a user-
of the intuitive controller. It suits both hotels and auditori- friendly manner with the aid of the intuitive controller. It suits
ums, as well as the home and living space. both hotels and auditoriums, as well as the home and living
space. As a design element, the Touch 16Ch Pro is ideally
touch interface implemnted in the living space.
optional DMX512 or analogous 0-10V
fade time setting from 0.01 to 10s 4 zones with 4 channels each
dimming steps 0-100% colour mode for the color setting in each single zone
LED display program mode for the color change and fader setting
4 storage locations for each zone
EEPROM memory time mode for setting the start and end time of the
DMX out: 3 pin green terminal programs
DC in: 2 pin green terminal 14 pre-installed or 8 auto-created programs
0 - 10V out: 2 pin green terminal can be assigned to one scene
dimensions L x W x H: 86 x 86 x 15,3 mm internal clock to switch the zones time-dependently
with the saved programs
DMX out: 3 pin green terminal
DC in: 2 pin green terminal
843005 black
dimensions L x W x H: 86 x 86 x 15,3 mm
12-24 0-10 1
68 Volt
843004 black
12-24 4 x 4
68
accessories accessories
872627 power supply 24V/8W 872627 power supply 24V/8W
702 CONTROLLER | DMX-wall controller
