P. 707

KAPEGO LED DIMMER 2                          KAPEGO LED DIMMER 3

         ‚ simple and powerful 1-2 channel dimmer      ‚ simple and powerful 3 channel dimmer
         ‚ to be used as a single device or in connection      ‚ to be used as a single device or in connection
         with a control panel in an assembly          with a control panel in an assembly
         ‚ flicker-free                                ‚ flicker-free
         ‚ connection  4 terminals [2xV+, 2xV-]        ‚ connection  6 terminals [3xV+, 3xV-]
         ‚ controller   DMX, 0-10V, manuell, automatic    ‚ controller   DMX, manuell, automatic
         ‚ dimensions L x W x H: 115 x 57 x 25 mm      ‚ dimensions L x W x H: 115 x 57 x 25 mm
         ‚ power   2x 72W at 12V, 2x 144W at 24V       ‚ power   144W at 12V, 288W at 24V

       843336     black                             843335     black


        12-24  CV  1 - 2    1-10                     12-24  CV  3
                            Volt

       706 CONTROLLER | DMX-dimmer
