P. 705
KAPEGO ART 4 | RGBW KAPEGO ART 9 | RGBW
The ART 4 controller is a touch panel for playing and editing The ART 9 controller is a touch panel for playing and editing
color programs, specifically for RGBW end devices. Up to 4 color programs, specifically for RGBW end devices. Up to 9
atmospheres and up to 4 scenes can be saved and retrieved. atmospheres and up to 9 scenes can be saved and retrieved.
Thee ART-4 contains 4 function menus: Selection of inte- The ART-4 contains 4 function menus: Selection of integra-
grated programs, color, brightness, speed setting. Scenes ted programs, color, brightness, speed setting. Scenes and
and atmospheres are created in a quick and user- friendly atmospheres are created in a quick and user-friendly manner.
manner. As a design element, the ART 4 controller is ideally As a design element, the ART 9 controller is ideally suited in
suited in the environment and is an appropriate choice both the environment and is an appropriate choice both for hotels
for hotels and auditoriums and the home and living space. and auditoriums and the home and living space.
PWM out for the direct control of LED devices control element and controller via touchwheel
output of DMX 512 for controlling further dimmers fade time setting for switch on/off and color change
· control element and controller via touchwheel function memory and power failure protection
fade times of 0-4 seconds possible DMX out: 4 pin green terminal
DMX out: 4 pin green terminal link in: 4 pin green terminal
DC in / PWM out: 7 pin green terminal link out: 4 pin green terminal
power out: 4 channels each 2A DC in / PWM out: 7 pin green terminal
dimensions L x W x H: 86 x 86 x 15,3 mm 4 channels each 2A, max. 8A in total
integrated PWM-dimmer 12/24V, 4 x 2A dimensions L x W x H: 172 x 86 x 15,3 mm
843003 black
843000 black
12-24 4
12-24 4 68
68
accessories accessories
872627 power supply 24V/8W 872627 power supply 24V/8W
704 CONTROLLER | DMX-wall controller
