Page 710 - Deko-Light Light Impressions 2019-20
P. 710
KAPEGO R-DMX 3+1 KAPEGO HV DMX 135W
RDM means »Remote Device Management«. This remote compact DMX combi device for simple and quick
device management enables the control of the RDMX 3+1 installation
from the control panel. This provides a great advantage, one housing combines a powerful 3 channel dimmer
specifically for inaccessible installations or sites that are
difficult to reach. After installing the components, the RDMX as well as a 135 watt power supply
3+1 and its connected LED end devices logs on automatical- controlled with all 3 channel control panels
ly in the control panel. Now, the required DMX channels can supports DMX512
be assigned or changed via the control panel, without any dimmable from 0 - 100%
further settings being required for the remote RDMX 3+1 If soft dimming without flickering
RDM is not available, the DMX address assignment can also
be set manually via the DIP switch. For this purpose, the dimensions L x W x H: 196 x 75 x 40 mm
entire system must be RDM compatible. total power 135W
complies with the DMX 512/1990, RDM protocol/2009 843274 black 12V 3 x 45W
supports automatic DMX addressing 843275 black 24V 3 x 45W
incl. top-hat rail adapter
incl. 2m CAT5 cable [RJ45] 110-240 CV max 135 3 CAT
connection 1, 2, 3, 4, V+ 5
dimensions L x W x H: 120 x 43 x 23 mm
power 192W at 12V, 384W at 24V
843273 black
12-24 CV 3 / 4 CAT
5
CONTROLLER | DMX-dimmer 709
