Page 873 - Deko-light Catalogue 2022

P. 873

D FLEX LINE TOP VIEW IP68 RGB

9,5 mm
8,33 mm 50 mm / 6 LED 180°

r 75 mm
stripe length: 5 m max. total length to be operated: 5 m minimum bending radius

9,5 mm
feed-in: 3000 mm secondary feed-in: 3000 mm

840286 5 m roll 460-620 nm 120 LED/m 10 W/m 31,5 lm/W 315 lm/m 469,95 €

24 SMD - 15°C
CV 4040 3 CH IP68 + 50°C

incl. accessories: 10x retaining clip, 10x screw, 2x endcap

930446 proﬁle for D Flex Line MINI 12,95 €
aluminium anodized
L x W x H: 1000 x 12 x 13 mm
930445 proﬁle for D Flex Line MINI 9,95 €
plastic | transparent
L x W x H: 1000 x 12 x 13 mm
930531 assembly set for D Flex Line | 10 x 10 mm 8,95 €
930593 gel glue for gluing the end caps 3g 4,95 €

LED STRIPES | D FLEX LINE Top View | 3CH | 24V | IP68 871
