Additional
inlets were
made in the
bottom of
the fuselage.

CortexPro gyro,
Central Box 200 and
Electron gear
electronics GS-200
are cleanly installed.

of wood, CfK reinforcements, fits, prefabrication - every-
thing is great.
There are various accessories available for the model.
We have decided on the electric Electron retractable lan-
ding gear including brakes and the thrust tube including
vector control. The following components were installed in
the model:
• Receiver 2 x Jeti REX3
1 x Jeti Rsat 900
• Receiver battery 2 x 2s / 2,600 mAhJeti LiIon,
• Servos 13 x MKS DS9910XJ, force 26 kg at 6 V
• Power supply Jeti CentralBox 200
• BECs Jeti for stabilised Power supply of the CB200
• Gyro Cortex Pro
• Thrust / Vector Tube CARF Models
• Smoke pump KingTech SP850
• Turbine KingTech K320G2
• Fuelbag.de fuel tank system
• Turbine telemetry & fuel monitoring VSpeak
ECU converter

A bagged
tank was
also used
for the
smoke
oil.
