EXTRA HIGH CAPACITY BULK RACK Best Value on the Market - Up to 3800 lbs. Per Shelf

This cost-effective, sturdy metal storage rack offers
almost twice the capacity per level as standard racks
thanks to the formed step Z-beam. Boltless design
Easy to Assemble! allows horizontal beams to install easily without tools
and to adjust in seconds at 2” increments. Heavy-duty
12-gauge beams have 3 hooks at each end for positive
connection. Uprights are 14-gauge steel measuring 1 3 /4”
x 1 3 /4”. Gray powder coat finish. Easy assembly.

Starter Unit Add-On Unit
Choose the Decking that suits your needs: No Deck, Includes 2 upright Includes 1 upright
frames, 3 shelf levels
Wood, Wire or Steel and 15 deck supports. frame, 3 shelf levels
Wood Deck - Low cost, precut 5 /8” thick particleboard and 15 deck supports.
Wire Deck - Allows visibility and light, air and sprinkler Models 18” depth units do not include deck supports.
penetration (reducing insurance premiums)
Epoxy finish.
Steel Deck- Long lasting, smooth surface.
DECK
SUPPORTS
WOOD DECK

THREE HOOKS FOR 14 GAUGE DECK SAFETY PIN FOOT PLATES ALLOW FORMED STEP BEAM
POSITIVE CONNECTION SUPPORTS LOADS LOCKS BEAMS IN PLACE RACK TO BE BOLTED TO CREATES EXTRA
THE FLOOR SUPPORT FOR
INCREASED CAPACITY

Cap NO DECK WOOD DECK WIRE DECK STEEL DECK
Lbs./ STARTER ADD-ON STARTER ADD-ON STARTER ADD-ON STARTER ADD-ON
W” x D” x H” Level Model Model Model Model Model Model Model Model
60 x 18 x 72 3800 SC504530 SC504533 SC504590 SC504591 – – – –
60 x 24 x 72 3800 SC504407 SC504434 SC504281 SC504308 SC504464 SC504491 SC504344 SC504371
60 x 36 x 72 3800 SC504408 SC504435 SC504282 SC504309 SC504465 SC504492 SC504345 SC504372
60 x 48 x 72 3800 SC504409 SC504436 SC504283 SC504310 SC504466 SC504493 SC504346 SC504373
72 x 18 x 72 2750 SC504531 SC504534 SC504536 SC504538 SC504542 SC504544 – –
72 x 24 x 72 2750 SC504410 SC504437 SC504284 SC504311 SC504467 SC504494 SC504347 SC504374
72 x 36 x 72 2750 SC504411 SC504438 SC504285 SC504312 SC504468 SC504495 SC504348 SC504375
72 x 48 x 72 2750 SC504412 SC504439 SC504286 SC504313 SC504469 SC504496 SC504349 SC504376
96 x 18 x 72 2150 SC504532 SC504535 SC504537 SC504539 SC504543 SC504545 – –
96 x 24 x 72 2150 SC504413 SC504440 SC504287 SC504314 SC504470 SC504497 SC504350 SC504377
96 x 36 x 72 2150 SC504414 SC504441 SC504288 SC504315 SC504471 SC504498 SC504351 SC504378
96 x 48 x 72 2150 SC504415 SC504442 SC504289 SC504316 SC504472 SC504499 SC504352 SC504379
60 x 24 x 96 3800 SC504416 SC504443 SC504290 SC504317 SC504473 SC504500 SC504353 SC504380
60 x 36 x 96 3800 SC504417 SC504444 SC504291 SC504318 SC504474 SC504501 SC504354 SC504381
60 x 48 x 96 3800 SC504418 SC504445 SC504292 SC504319 SC504475 SC504502 SC504355 SC504382
72 x 24 x 96 2750 SC504419 SC504446 SC504293 SC504320 SC504476 SC504503 SC504356 SC504383
72 x 36 x 96 2750 SC504420 SC504447 SC504294 SC504321 SC504477 SC504504 SC504357 SC504384
72 x 48 x 96 2750 SC504421 SC504448 SC504295 SC504322 SC504478 SC504505 SC504358 SC504385
96 x 24 x 96 2150 SC504422 SC504449 SC504296 SC504323 SC504479 SC504506 SC504359 SC504386
96 x 36 x 96 2150 SC504423 SC504450 SC504297 SC504324 SC504480 SC504507 SC504360 SC504387
96 x 48 x 96 2150 SC504424 SC504451 SC504298 SC504325 SC504481 SC504508 SC504361 SC504388
60 x 24 x 120 3800 SC504425 SC504452 SC504299 SC504326 SC504482 SC504509 SC504362 SC504389
60 x 36 x 120 3800 SC504426 SC504453 SC504300 SC504327 SC504483 SC504510 SC504363 SC504390
60 x 48 x 120 3800 SC504427 SC504454 SC504301 SC504328 SC504484 SC504511 SC504364 SC504391
72 x 24 x 120 2750 SC504428 SC504455 SC504302 SC504329 SC504485 SC504512 SC504365 SC504392
72 x 36 x 120 2750 SC504429 SC504456 SC504303 SC504330 SC504486 SC504513 SC504366 SC504393
72 x 48 x 120 2750 SC504430 SC504457 SC504304 SC504331 SC504487 SC504514 SC504367 SC504394
96 x 24 x 120 2150 SC504431 SC504458 SC504305 SC504332 SC504488 SC504515 SC504368 SC504395
96 x 36 x 120 2150 SC504432 SC504459 SC504306 SC504333 SC504489 SC504516 SC504369 SC504396
96 x 48 x 120 2150 SC504433 SC504460 SC504307 SC504334 SC504490 SC504517 SC504370 SC504397
