Page 87 - Repower Reference Guide (2020) 8M0149179

PROPELLERS FOR PLUS SERIES ENGINES

357 MAG BRAVO ONE

Plus Series ‑ 357 MAG Bravo 4V ‑ (325 HP) ‑ V8 Bravo One
Propellers ‑ For Single Engine Boats
WOT: 4400‑4800 RPM, Standard Gear Ratio 1.50:1
High Altitude (5,000+ ft.) Gear Ratio: 1.65:1
Right Hand Rotation Standard
Diameter (inches) Pitch (inches) Blades Material Approx. Gross Boat Wgt. (lbs.) Approx. Boat Length (ft.) Speed Range (mph)
15.75 15 3 Stainless Steel 6000-7700 25-28' 32-40
15.50 17 3 Stainless Steel 5100-6200 24-26' 39-46
15.25 19 3 Stainless Steel 4500-5100 23-25' 46-52
14.75 21 3 Stainless Steel 3800-4500 22-24' 52-58
14.63 23 3 Stainless Steel 3600-4000 Up to 23' 56-63
13.50 17 5 Stainless Steel 5100-6200 24-26' 39-46
13.25 19 5 Stainless Steel 4500-5100 23-25' 46-52
13.25 21 5 Stainless Steel 3800-4500 22-24' 52-58
MERCRUISER Plus Series ‑ 357 MAG Bravo 4V ‑ (325 HP) ‑ V8 Bravo One (Twin Engine)
Propellers ‑ For Twin Engine Boats
WOT: 4400‑4800 RPM, Standard Gear Ratio 1.50:1
High Altitude (5,000+ ft.) Gear Ratio: 1.65:1
Right & Left Hand Rotation Required for Twins
Diameter (inches) Pitch (inches) Blades Material Approx. Gross Boat Wgt. (lbs.) Approx. Boat Length (ft.) Speed Range (mph)
15.75 15 3 Stainless Steel 12000-15400 31-34' 32-41
15.50 17 3 Stainless Steel 10000-12300 29-32' 39-47
15.25 19 3 Stainless Steel 8800-10300 28-30' 45-53
14.75 21 3 Stainless Steel 7800-9000 27-29' 51-58
14.63 23 3 Stainless Steel 7200-8000 Up to 28' 56-63

357 MAG BRAVO THREE

Plus Series ‑ 357 MAG Bravo 4V ‑ (325 HP) ‑ V8 Bravo Three
Propellers ‑ For Single Engine Boats
WOT: 4400‑4800 RPM, Standard Gear Ratio 2.20:1
High Altitude (5,000+ ft.) Gear Ratio: 2.43:1

Diameter (inches) Pitch (inches) Blades Material Approx. Gross Boat Wgt. (lbs.) Approx. Boat Length (ft.) Speed Range (mph)
16.00 20 4 Stainless Steel 7000-9300 26-30' 27-35
14.38 20 3 Stainless Steel 7000-9300 26-30' 27-35
15.75 22 4 Stainless Steel 6000-7700 25-28' 32-40
14.25 22 3 Stainless Steel 6000-7700 25-28' 32-40
15.50 24 4 Stainless Steel 5400-6500 24-27' 37-44
14.25 24 3 Stainless Steel 5400-6500 24-27' 37-44
15.25 26 4 Stainless Steel 4900-5800 23-26' 41-48
14.00 26 3 Stainless Steel 4900-5800 23-26' 41-48
15.00 28 4 Stainless Steel 4500-5100 Up to 25' 46-52
13.75 28 3 Stainless Steel 4500-5100 Up to 25' 46-52

70
