ELECTRICAL

TACHOMETER HARNESSES REMOTE CONTROL ADAPTER HARNESSES

TACHOMETER HARNESS REMOTE CONTROL ADAPTER HARNESS

84- 46239A 1 84-892473A01
Three blade style. Used with 61490A__ series controls and ignition/Choke panels Converts the traditional Mercury connector to an Amp 8‑pin connector.
77777A 2 and A 4. Converts side mount controls 881170A 3, 15, 16 and the 816626A_ series ignition
keyswitch harness to connect to the MY2005 and newer 8/9.9 hp. FourStroke
TACHOMETER HARNESS outboard.
MY2005 and newer 8/9.9 hp. FourStroke outboard and the 15/20 hp. FourStroke
(351cc) outboard when a 8 pin side mount control or keyswitch harness is used.
REMOTE CONTROL/IGNITION CHOKE EXTENSION
ELECTRICAL HARNESSES

Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin)
outboards, Mariner 30/40 hp. with oil injection (2 cycle, Japanese
Origin), all Mercury / Mariner 4‑Stroke (USA Origin) outboards and
Force 40 hp. and Higher (1993 and Newer). Various applications
include 7,8 and 10 pin harnesses and 12 wire (8 pin plus 4 bullet
84- 69108A 5 connectors) used on side mount controls and ignition/choke assemblies.
Four pin style. Used with 84‑87364A__ series harnesses, 65640A__ series
controls and 76334A__ series controls. EXTENSION HARNESS
TACHOMETER HARNESS

84- 17829A 2
84- 86396A 8 2 ft.(0.6 m) harness, 8 lead harness.
Five pin style. 4 ft.(1.2 m). Used with Commander, Commander 2000 series & MSC Used as harness extension or to complete two station installations.
4000 (8 pin) series side mount controls and Ignition/Choke assemblies. 84- 17829A10
84- 86396A24 10 ft.(3.05 m) harness, 8 lead harness.
Five pin style. 13 ft.(4 m). Used with Commander, Commander 2000 series & MSC Used as harness extension or to complete two station installations.
4000 series side mount controls and Ignition/Choke assemblies. 84- 17829A20
20 ft.(6.1 m) harness, 8 lead harness.
TACHOMETER HARNESS Used as harness extension or to complete two station installations.

84-827593A 2
Bullet pin style.
Fits Mercury/Mariner 30 to 90 electric start tiller handle models.
