MECHANICAL REMOTE CONTROLS

883710A03 140.07 MCC 4500 CONSOLE MOUNT - SINGLE ENGINE
The Panel Mount control features a chrome handle and comes with a 4ft.
(1.22 m) trim harness with the 4 pin molex connector. All installations
require a separate Ignition/Choke assembly and T/S cables to complete A single station control with rubberized grip on a redesigned handle
the installation. The neutral safety switch leads are 6.5 ft. (1.98 m) and have a offering smooth operation and quick response. Throttle only button at
bullet connector on the ends. The lanyard switch leads also have bullet style base of handle.
connector ends.
Fits all current MCM (with integral trim) utilizing Mercury style cables (with power
trim). CONSOLE MOUNT REMOTE CONTROL-GEN II
Mercury Branded
BEZEL KIT-CUSTOM UPGRADE

8M0060782 168.14
This control is designed for MIE inboards and outboards w/o power trim. All
installations require an Ignition/Choke harness and T/S cables to complete
891648001 25.69 the installation.
Woodgrain cover allows you to customize the look of your control. Snap out the Fits MIE inboards and all current Mercury/Mariner outboards (without power trim)
black inner bezel and snap in the custom bezel to enrich the appearance of your and 1993 and newer Force outboards 40 HP and higher utilizing Mercury style
control. cables (without power trim).
Use on 4000 Gen II Panel Mount controls‑ Lock Bar one piece design 8/9.9 FourStroke engines 2005 and newer will use GEN II/SAE Premium cables.
8/9.9 generation change above S/N OR192772 and 15/20 FourStroke will use Gen
BEZEL KIT-CUSTOM UPGRADE II T/S cables.
CONSOLE REMOTE CONTROL-GEN II-SINGLE

891648002 25.69
Burlwood Gold Woodgrain cover allows you to customize the look of your control. 8M0059686 175.93
Snap out the black inner bezel and snap in the custom bezel to enrich the This control features a single trim switch in the port handle for trim and
appearance of your control. comes with the trim harness (attached to switch) with the white connector.
Use on 4000 Gen II Panel Mount controls‑ Lock Bar one piece design All installations require an Ignition/Choke harness and T/S cables to
complete the installation.
Fits all current Mercury/Mariner outboards (with integral trim) and 1993 and newer
Force outboards 40 HP and higher utilizing Mercury style cables (with power trim).
8/9.9 FourStroke engines 2005 and newer and 8/9.9 generation change above S/N
OR192772 and 15/20 FourStroke will use Gen II T/S Cable.
