Page 129 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

MECHANICAL REMOTE CONTROLS

MSC 4000 SIDE MOUNT - ELECTRIC POWER TRIM 8M0103453 204.92
This control features a handle mounted power trim switch, 20 ft. (6.1 m)
harness, built‑in warning horn and includes power trim leads for front
SIDE MOUNT REMOTE CONTROL-14 PIN mount switch.
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and
newer Force outboards 40 HP and higher utilizing Mercury style cables (with power
trim). When used with MY2005 and newer 8/9.9, 15/20 FourStroke outboards an
adapter harness is required.
For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used.
GEN II cables must be used.
SIDE MOUNT REMOTE CONTROL- 10 PIN AMP
8M0103449 200.76
This control features a handle mounted power trim switch, 15 ft. (4.58 m)
harness with Amp 10‑pin connector. The control will connect to the engine
models below without the use of an adapter.
Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start
8M0083666 202.29 and power trim.
For MY2005 only 8/9.9 FourStroke outboards SAE T/S cables must be used.
This control features a handle mounted power trim switch and a 15 ft. (4.58 For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
m) harness with 14 pin Deutsch connector. The control will connect to the FourStroke engines will use GEN I cables.
engine models below without the use of an adapter harness. GEN II cables must be used on other engines.
SIDE MOUNT REMOTE CONTROL
For 2006 and newer non DTS 25‑300 HP Outboard engines. 8M0103450 204.92
GEN II cables must be used. This control features a handle mounted power trim switch, 20 ft. (6.1 m)
8M0083667 208.38 harness with Amp 10‑pin connector. The control will connect to the engine
This control features a handle mounted power trim switch and a 20 ft. models below without the use of an adapter harness.
(6.1 m) harness with 14 pin Deutsch connector. The control will connect to Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start
the engine models below without the use of an adapter harness. and power trim.
For 2006 and newer non DTS 25‑300 HP Outboard engines. For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used.
GEN II cables must be used. For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables.
SIDE MOUNT REMOTE CONTROL-14 PIN (PORT SIDE GEN II cables must be used on other engines.
MOUNT)
SIDE MOUNT REMOTE CONTROL- 14 PIN AMP
8M0121856 202.29
This control features a handle mounted power trim switch, 15 ft. (4.58 m) harness
with Amp 14‑pin connector. The control will connect to the engine models below
without the use of an adapter.
Fits all current Mercury/Mariner outboards 6 HP and above and 1993 and newer
Force outboards 40 HP and above (with power trim).
GEN II cables must be used.
MSC 4000 SIDE MOUNT - ELECTRIC NON-POWER
TRIM
8M0053636 197.21
This side mount control is for mounting on the port side and controlling with SIDE MOUNT REMOTE CONTROL- 14 PIN
the left hand. This control features a handle mounted power trim switch
and 15ft.(4.58m) harness with 14 pin Deutsche connector.
For 2006 and newer non DTS 25‑300 HP Outboard engines.
GEN I cables must be used.
No Adapter harness required.
SIDE MOUNT REMOTE CONTROL- 8 PIN TRADITIONAL

8M0083860 193.83
This control features non ‑ power trim and a 15ft. (4.58m) harness with 14
pin Deutsch connector.
Fits all current Mercury/Mariner Outboards 6 HP and above (without power
trim), and 1993 and newer Force Outboards 40 HP and higher utilizing Mercury
MECHANICAL REMOTE CONTROLS This control features a handle mounted power trim switch, 15 ft. Gen II cable must be used.
cables (without power trim).
When used with a MY2005 and newer 8/9.9, 15/20 FourStroke Outboard an
8M0103452
200.76
Adapter harness is required.
(4.58 m) harness, built‑in warning horn and power trim leads for front
mount switch.
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and
newer Force outboards 40 HP and higher utilizing Mercury style cables (with power
trim). When used with MY2005 and newer 8/9.9/15/20 FourStroke outboards an
adapter harness is required.
For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used.
GEN II cables must be used.
116
