Page 238 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

ELECTRICAL

ELECTRICAL ISOLATOR KIT- TRIPLE OPTI
BATTERY SWITCH
BATTERY SELECTOR SWITCH

8M0073038 259.48
Used to add Power steering option to Triple OptiMax engines
Triple OptiMax Engines
67-829721 41.09
BATTERY ISOLATOR HARNESS KIT Ignition protected. Standard features include a make before break design, for use
with two or more batteries, single or dual engine systems (for dual engine systems,
two switches are required). They permit selection between batteries for starting
and charging or operation of both batteries in parallel. They allow the addition of
an extra battery for use with accessories. The OFF position also acts as an
emergency disconnect in the event of an electrical problem. Surface mount, red
[plastic housing with large black plastic knob. Incorporates an improved design to
protect the copper contacts and brass terminals used as electrical connections.
For use with systems under 50 volts. Capacity: 250 amps continuous, 360 amps
intermittent. 5‑1/4 in. (133 mm) diameter, 2‑5/8 in. (67 mm) depth.
67-829722 49.47
With Alternator Field Disconnect. Ignition protected. Standard features include a ELECTRICAL
make before break design, for use with two or more batteries, single or dual engine
systems (for dual engine systems, two switches are required). They permit
selection between batteries for starting and charging or operation of both batteries
84-8M0094239 52.70 in parallel. They allow the addition of an extra battery for use with accessories.
Allows the connection of any battery isolator to Mercury/Mariner outboard. Kit The "OFF" position also acts as an emergency disconnect in the event of an
includes a 10 gauge red cable (8 ft.[2.44 m] length) that connects from the electrical problem. In addition to the standard features listed above, the advantage
regulator output terminal to the battery isolator input terminal. these models feature is that they will prevent damage to the alternator* if
Fits Mercury/Mariner 50‑125 hp. (2000 & prior) with high output (16 amp.) accidentally switched to the "OFF" position while the engine is running.
alternator and V‑6 models (1999 & prior) equipped with 40 amp. alternator or dual MAIN BATTERY SWITCH
20‑amp alternator systems and fits the F75‑115 hp. (2.1L) FourStroke and the
F150 EFI FourStroke outboard. Connections from battery isolator to the batteries
are not included.
BATTERY CABLE - 6 INCH, 16 GA

67-829723 39.55
Ignition protected. Standard features include a make before break design, for use
with two or more batteries, single or dual engine systems (for dual engine systems,
two switches are required). They permit selection between batteries for starting
and charging or operation of both batteries in parallel. They allow the addition of
an extra battery for use with accessories. The "OFF" position also acts as an
emergency disconnect in the event of an electrical problem. Ignition protected for
use with systems under 50 volts. Capacity: 250 amps continuous, 360 amps
84-8M0094651 1.23 intermittent.
6 inch red battery cable (component of isolator kit 8M0094239), 16 gauge
Can be used as part of a battery isolator kit , signal sense lead or short jumper ELECTRICAL HARDWARE
CABLE/FUSE ASY - 90 AMP -BATTERY ISOLATOR
ELECTRICAL HARDWARE KIT

84-898180K01 53.93
Improved heat handling capacity cable used with battery isolators and 86-813937A 2 79.40
Verado kits Contains a broad selection of the electrical connectors used on Mercury/Mariner/
Force and MerCruiser products.

OEM Rigging & Accessories Guide & Price List 225
