ELECTRICAL

VERADO BATTERY REQUIREMENTS BATTERY CABLE-NEG

Engines must use a marine starting battery with 1000 MCA or 800 CCA.
Do NOT use deep cycle batteries. When connecting engine battery, hex
nuts must be used to secure the battery leads to battery posts. Torque
nuts to 120 lb. in. (13.5 Nm). Hex nuts listed below are furnished with
each engine. Metric nuts are not provided. Battery cables are supplied
with Long models only. XL and XXL models do not have cables
packaged with the outboard.
HEX NUT

84- 88439A26 25.70
Single 12 ft. negative cable.
FUSE/HARNESS ASSEMBLY

11- 86226
ELECTRICAL 3/8‑16 Hex S.S. 1.00
HEX NUT

84-898289T77
New 3 FT fuse /harness asy will be used with the new 50 amp Power 18.03
Steering circuit. It will coneect from the APS moudule to the battery. Used
with Power Steering Pumps 892440A17,A18 and A19
Used on all Power Steering installations
84-898289T78 19.06
New 5 FT fuse /harness asy will be used with the new 50 amp Power
Steering circuit. It will coneect from the APS moudule to the battery. Used
with Power Steering Pumps 892440A17,A18 and A19
Used on all Power Steering installations
11- 68292 1.35 FUSE/HARNESS ASSEMBLY
5/16‑18 Hex S.S.
Priced individually, sold @ multiples of 5
BATTERY CABLE-POS

84-898289T79 23.44
New 10 FT fuse /harness asy will be used with the new 50 amp Power
Steering circuit. It will coneect from the APS moudule to the battery. Used
with Power Steering Pumps 892440A17,A18 and A19
84- 88439A25 25.80 Used on all Power Steering installations
Single 12 ft. positive cable.
