Page 365 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

MERCURY PROPELLER RIGGING CHART RH - Part Number Description LH - Part Number Performance
MERCURY PROPELLER RIGGING CHART 15.60” 13 3 3 4 4 4 4 4500-7000 1-28 48-8M0070074 Enertia 48-8M0070076 Category

Boat Weight
Diameter
No. of Blades
Pitch
Boat Speed
Comp Series
7000+
48-8M0070079
Enertia
11
Comp Series
16.00”
48-8M0070077
1-25
19
2500-3200
39-49
14.00"
SpitFire
Elite Series

48-8M0084495
Elite Series

17
2900-4000
32-43
SpitFire
48-8M0084494
14.00"
3800-6200
14.00"
SpitFire
14
48-8M0084493
22-34
Elite Series

1-25
14.00"
48-8M0084491
7000+
Elite Series

12
SpitFire
14.50"
17
2900-4000
32-43
15.00"
Black Max
48-832828A45
Sport Series
3400-5100
26-37
15
48- 78116A45
Black Max
15.25"
Sport Series
Sport Series
Black Max
16.00" 19 3 3 3 3 2500-3200 39-79 48-832830A45 Black Max Sport Series
1-28
4500-7000
48- 78114A45
13
16.00" 11 3 7000+ 1-25 48- 78112A45 Black Max Sport Series
115 CT HP FourStroke ‑ Tri / Pontoon
Engine RPM Range: 5000‑6000 Gearcase Ratio: 2.38:1
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description LH - Part Number Performance
Category
13.50” 22 3 2000-2800 35-47 48-899202A46 Enertia Comp Series
13.80” 21 3 2100-3100 32-45 48-899002A46 Enertia 48-899003A46 Comp Series
13.75” 20 3 2300-3500 29-42 48-899000A46 Enertia Comp Series
14.00” 19 3 2400-3700 27-40 48-898998A46 Enertia 48-898999A46 Comp Series
14.20” 18 3 2600-4300 24-37 48-898996A46 Enertia Comp Series
14.50” 17 3 2800-5000 21-35 48-898994A46 Enertia 48-898995A46 Comp Series
14.70” 16 3 3100-5600 19-32 48-898992A46 Enertia Comp Series
15.00” 15 3 3500-6700 16-29 48-898990A46 Enertia 48-898991A46 Comp Series
15.30” 14 3 3900-7800 14-26 48-898988A46 Enertia 48-8M0079504 Comp Series
15.60” 13 3 4300-10300 11-24 48-8M0070074 Enertia 48-8M0070076 Comp Series
16.00” 11 3 7000+ 1-18 48-8M0070079 Enertia 48-8M0070077 Comp Series
14.00” 23 4 1900-2600 38-49 48-8M0084497 SpitFire Elite Series
14.00” 21 4 2100-3100 32-45 48-8M0084496 SpitFire Elite Series
14.00” 19 4 2400-3700 27-40 48-8M0084495 SpitFire Elite Series
14.00” 17 4 2800-5000 21-35 48-8M0084494 SpitFire Elite Series
14.00” 14 4 3900-7800 14-26 48-8M0084493 SpitFire Elite Series
14.00” 12 4 7000+ 1-24 48-8M0084491 SpitFire Elite Series
14.50” 19 3 2400-3700 27-40 48-832830A45 Black Max Sport Series
15.00” 17 3 2800-5000 21-35 48-832828A45 Black Max Sport Series
15.25” 15 3 3500-6700 16-29 48- 78116A45 Black Max Sport Series
16.00” 13 3 4300-10300 11-24 48- 78114A45 Black Max Sport Series
16.00” 12 3 5000+ 9-21 48- 16436A45 Black Max Sport Series
16.00” 11 3 7000+ 1-18 48- 78112A45 Black Max 48- 78117A40 Sport Series
115 STD HP FourStroke ‑ Tri / Pontoon
Engine RPM Range: 5000‑6000 Gearcase Ratio: 2.07:1
Diameter Pitch No. of Blades Boat Weight Boat Speed RH - Part Number Description Performance Category
12.7" 21 4 1800-2400 40-52 48-8M0055551 SpitFire X7 Elite Series
12.7" 19 4 2000-2900 34-47 48-8M0055550 SpitFire X7 Elite Series
13.0" 17 4 2300-3600 28-41 48-8M0055549 SpitFire X7 Elite Series
13.5" 15 4 2800-4700 22-35 48-8M0055548 SpitFire X7 Elite Series
14.0" 13 4 3500-6700 16-29 48-8M0055547 SpitFire X7 Elite Series
13” 18 3 2200-3200 31-44 48- 16988A46 Vengeance Sport Series
13.13” 16 3 2500-4100 25-38 48- 16986A46 Vengeance Sport Series
13.25” 15 3 2800-4700 22-35 48-854354A46 Vengeance Sport Series
13.38” 14 3 3100-5600 19-32 48- 17314A46 Vengeance Sport Series
