MERCURY RACING PROPELLER CHARTS

Diameter Pitch Pro Finished LH Rotaion Pro Finished RH Bravo I OC Lab Finished Outboard Propeller Chart
Rotaion
Polished Lab Finished, reduced diameter with added tip cup, shortened barrel to
14.6 17 In Process In Process
minimize stern lift and equipped with dual PVS for quick planing. Hub Kit Sold
14.6 17.5 In Process In Process separately, 835258K2 for 1 inch or 840389K06 for 1.25 inch propshaft.
14.6 18 48-8M0113929 48-8M0113928
Used with Torque or Sport Master gearcase.
14.6 18.5 48-8M0113931 48-8M0113930
14.6 19 48-8M0113933 48-8M0113932
Diameter Pitch Pro Finished LH Pro Finished RH
14.6 19.5 48-8M0113935 48-8M0113934 Rotation Rotation
14.6 20 48-8M0113937 48-8M0113936 14.75 26 48-8M0129147
14.6 20.5 48-8M0113939 48-8M0113938 14.75 26.5 48-8M0129148
14.6 21 48-8M0113941 48-8M0113940 14.75 27 48-8M0129149
14.6 21.5 48-8M0113943 48-8M0113942 14.75 28 48-8M0092003 48-8M0092002
14.6 22 48-8M0113945 48-8M0113944 14.75 29 48-8M0092005 48-8M0092004
14.6 22.5 48-8M0113947 48-8M0113946 14.75 30 48-8M0092007 48-8M0092006
14.6 23 48-8M0113949 48-8M0113948 14.75 31 48-8M0092009 48-8M0092008
14.6 23.5 48-8M0113951 48-8M0113950 14.75 32 48-8M0092011 48-8M0092010
14.6 24 48-8M0113953 48-8M0113952 14.75 33 48-8M0092013 48-8M0092012
14.6 24.5 48-8M0113955 48-8M0113954 14.75 34 48-8M0092015 48-8M0092014
14.6 25 48-8M0113957 48-8M0113956 14.75 35 48-8M0092017 48-8M0092016
14.6 25.5 48-8M0113959 48-8M0113958
14.6 26 48-8M0128847 48-8M0128846 BRAVO I - 4 BLADE SS LAB FINISHED WITH PVS
14.6 26.5 48-8M0128850 48-8M0128849

REVOLUTION 4 LAB FINISHED PROPELLER

Bravo I 4 Blade SS Lab Finished Outboard Propeller Chart
The Lab Finished Bravo I features a high luster finish and dual PVS vent holes per
blade. Hub Kit Sold Separately use 835258K2 for 1 inch or 840389K06 for 1.25
inch Propshaft
Revolution 4 Lab Finished Chart Diameter Pitch Lab Finished LH Lab Finished RH
Rotation Rotation
For multi‑engine outboard powered Center Console and single engine Bay Boats.
Hub Kit Sold Separately use 835258K2 for 1 inch or 840389K06 for 1.25 inch 15.25 22 48-831909L66 48-831910L66
Propshaft 15.25 23 48-831909L46 48-831910L46
15.25 24 48-831911L66 48-831912L66
Diameter Pitch Lab Finished LH Rotaion Lab Finished RH 15.25 25 48-831911L46 48-831912L46
Rotaion
15.25 26 48-831913L66 48-831914L66
14.6 19 48-857027L55 48-857026L55
15.25 27 48-831913L46 48-831914L46
14.6 20 48-8M0106547 48-8M0106548
15.25 28 48-831915L66 48-831916L66
14.6 21 48-857029L55 48-857028L55
15.25 29 48-831915L46 48-831916L46
14.6 22 48-8M0106545 48-8M0106546
15.25 30 48-831917L66 48-831918L66
14.6 23 48-857031L55 48-857030L55
15.25 32 48-831919L66 48-831920L66
14.6 24 48-8M0106543 48-8M0106544
15.25 34 48-832121L66 48-832122L66
14.6 25 48-857033L55 48-857032L55
15.25 36 48-832123L66 48-832124L66
BRAVO I OC LAB FINISHED MERCURY RACING PROPELLER CHARTS
