Page 429 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

MERCURY RACING PROPELLER CHARTS

BRAVO I - 4 BLADE SS LAB FINISHED Diameter Pitch Lab Finished LH Lab Finished RH
Rotation
Rotation
15 26 48-8M0117993 48-8M0117992
15 27 48-8M0117995 48-8M0117994
15 27.5 48-8M0117997 48-8M0117996
15 28 48-8M0117999 48-8M0117998
15 29 48-8M0118001 48-8M0118000
15 29.5 48-8M0118003 48-8M0118002
15 30 48-8M0118005 48-8M0118004
15 31 48-8M0118007 48-8M0118006
15 31.5 48-8M0118009 48-8M0118008
Bravo I 4 Blade SS Lab Finished Sterndrive and 4 Stroke 15 32 48-8M0118011 48-8M0118010
Outboard Chart 15 33 48-8M0118013 48-8M0118012
New for 2014 the Lab Finished Bravo I features Polished finish. Hub Kit Sold 15 33.5 48-8M0118015 48-8M0118014
separately use 835258K2 for 1 inch and 840389K06 for 1.25 inch Propshaft. The 15 34 48-8M0118017 48-8M0118016
L35 has superseded to the L45 and the L55 superseded to L65.
Diameter Pitch Lab Finished LH Lab Finished RH MAXIMUS ST PRO FINISHED
Rotation Rotation
15.25 22 48-831909L65 48-831910L65
15.25 23 48-8M0073457 48-8M0073456
15.25 24 48-831911L65 48-831912L65
15.25 25 48-831911L45 48-831912L45
15.25 26 48-831913L65 48-831914L65
15.25 27 48-831913L45 48-831914L45
15.25 28 48-831915L65 48-831916L65
15.25 29 48-831915L45 48-831916L45
15.25 30 48-831917L65 48-831918L65
Maximus ST Pro Finished Propeller Chart
15.25 31 48-831917L45 48-831918L45
15.25 32 48-831919L65 48-831920L65 Pro Finished Maximus with 7.875 inch barrel length reducing stern lift, full and
reduced diameter to accommodate X dimensions. Hub Kit Sold Separately, for
15.25 33 48-831919L45 48-831920L45
Mercury use 835258K2 for 1 inch or 840389K06 for 1.25 inch propshaft.
15.25 34 48-832121L65 48-832122L65
15.25 35 48-832121L45 48-832122L45 Diameter Pitch Lab Finished LH Lab Finished RH
Rotation Rotation
15.25 36 48-832123L65 48-832124L65
15.6 24 48-8M0091991 48-8M0091990
15.25 37 48-832123L45 48-832124L45
15.3 24 48-8M0091979 48-8M0091978
MAX 5 LAB FINISHED PROPELLER 15.6 26 48-8M0091993 48-8M0091992
15.3 26 48-8M0091981 48-8M0091980
15.6 28 48-8M0091995 48-8M0091994
15.3 28 48-8M0091983 48-8M0091982
15.6 30 48-8M0091997 48-8M0091996
15.3 30 48-8M0091985 48-8M0091984
15.6 32 48-8M0091999 48-8M0091998
15.3 32 48-8M0091987 48-8M0091986
15.6 34 48-8M0092001 48-8M0092000
15.3 34 48-8M0091997 48-8M0091988
MAX 5 Lab Finished Propeller Chart MAXIMUS LONG TUBE 5 BLADE SS LAB FINISHED
Lab Finished with high polished designed for high Outboard Sport Master engine
heights; goal is to reduce prop slip that may occur with the 4 blade props. Hub Kit
MERCURY RACING PROPELLER CHARTS 416 Pitch Lab Finished LH Lab Finished RH Place Orders | Print Invoices | Register Product | Pay Online
Sold Separately, for Mercury use 835258K2 for 1 inch or 840389K06 for 1.25 inch
propshaft.
Diameter
Rotation
Rotation
15
23
48-8M0117982
48-8M0117983
48-8M0117984
15
23.5
48-8M0117985
48-8M0117987
48-8M0117986
15
24
48-8M0117989
25
15
48-8M0117988
15
48-8M0117990
25.5
48-8M0117991
