P. 213
ELECTRICAL
TACHOMETER HARNESS SIDE MOUNT CONTROL HARNESS
84-827593A 2 24.75 84-8M0101080 77.83
WARNING: Cancer - www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Bullet pin style. 15 foot side mount control non‑trim harness
Fits Mercury/Mariner 30 to 90 electric start tiller handle models. Comes in 8M0083860 Side Mount Control with non‑Trim kit
ADAPTER- POWER TRIM O/B
REMOTE CONTROL ADAPTER HARNESSES
ADAPTER HARNESS FOR P/T INTERFACE
ELECTRICAL
84-824783A11 6.93
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Connects the white 3 pin trim connector (newer controls) to the old black boot
84-898286T01 4.42 connector on the harness
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov O/B backfit adapter ‑ new control and old harness
Allows the adaptation from the old black connector to the new white
connector for power trim. Allow direct plug in with new 14 pin connector NEUTRAL SWITCH ADAPTER - FEMALE
harness (896537__ series)
Converts Power Trim from old black 3 pin connector to new white 3 pin connector‑
(Ref 88688__ series controls as well as older models needing to match proper trim
connectors)
SIDE MOUNT CONTROL HARNESS
84-8M0143199 80.12
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
15 foot side mount control with trim harness 84-8M2100450 3.91
Used with Side Mount Control with trim WARNING: Cancer - www.P65Warnings.ca.gov
SIDE MOUNT CONTROL HARNESS Female bullet to flat spade connector
Used when needed to adapt to the Neutral Switch
NEUTRAL SWITCH ADAPTER - MALE
84-8M0143200 87.85
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
20 foot side mount control with trim harness 84-8M2100451 3.91
WARNING: Cancer - www.P65Warnings.ca.gov
Male bullet to flat spade connector
Used when needed to adapt to the Neutral Switch
