ELECTRICAL

75095Q 2 7.85 TRIM LIMIT KITS
Replacement cap for (65503A__ and 856654A__ series) Lanyard Stop Switches.
Fits Mercury/Mariner outboards and MCM/MIE engines. Trim limit kits available to adjust trim up limits
Priced individually, sold @ multiples of 2
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
POWER TRIM SWITCH KIT
LANYARD CORD - 54 INCH

87- 18286A46 46.82
8M0092850 9.13 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Lanyard cord with new ergonomic plastic clip, 54 inches in length. Rocker switch style with 25 ft.(7.62 m) harness and bullet connectors. Can be
Can be utilized on any Mercury Marine/Quicksilver lanyard stop switch at surface mounted or flush mounted. Provides tilt control from the bow or transom
the helm. Does not work with engine mounted stop switches. location.
Fits Mercury/Mariner 75‑115 hp. FourStroke outboards beginning with serial
Priced individually, sold @ multiples of 2 number 1B366823‑2B094955.
ELECTRICAL LANYARD ASSEMBLY
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
TRIM LIMIT SWITCH KIT

8M0164890 9.13
Lanyard cord assembly kit, 54 in.
LANYARD ASSEMBLY- 70 INCH

899625K02 52.13
8M0165957 5.00 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Lanyard cord assembly, 70 in. Limits the up travel of the power trim to minimize potential interferences
when fully tilted. This is an analog device.
Fits the Mercury/Mariner Opti Max 1.5L (75‑115), 2.5L (135,150,175 and
POWER TRIM CONTROL PANELS 3.0L (200‑300) Can also be used in 75‑115hp 1.7L 4‑stroke engines (Serial
number 1B366823‑2B094955.)
DUAL ENGINE POWER TRIM CONTROL TRIM LIMIT SWITCH KIT

90362A 3 388.18 899625K04 54.38
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Toggle switch style with 20 ft.(6.1 m) harness and circuit control box. Mounts in a Limits the up travel of the power trim to minimize potential interferences
3‑3/8 in.(86 mm) hole. Designed for dual engine installations equipped with when fully tilted. This is a digital device.
externally mounted tie bars. Simultaneously tilts both drives with a single toggle
switch. Fits the Mercury/Mariner Opti Max 1.5L (75‑115), 2.5L (135,150,1750 and
Fits Alpha & Bravo sterndrives that are not equipped with Auto Trim. 3.0L (200‑250) Can also be used in 75‑115 4 stroke engines (Serial number
1B366823 and above. (ref 14 Pin Harness)
