STEERING

HYDRAULIC HELM PUMP -Q/S HYDRAULIC HELM PUMP -Q/S-TILT

64-891665Q04 412.06 64-891666Q03 442.82
Front Mount 2.0 cu in displacement. Approximately 4 turns lock to lock on Front Mount 2.0 cu in displacement. Approximately 4 turns lock to lock on
singles singles
and 8 on dual cylinders and 8 on dual cylinders
Compact design Compact design
Built‑in valve for positive rudder lock Tilt Range of 48 Deg and 5 locking positions
Integral relief valve for over pressure protection Built‑in valve for positive rudder lock
Hydraulic Steering for Verado 135 to 200‑4 stroke engines Integral relief valve for over pressure protection
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses Hydraulic Steering for Verado 135 to 200‑4 stroke engines
64-891665Q05 418.39 Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
Front Mount 2.4 cu in displacement. Approximately 3 turns lock to lock on 64-891666Q04 455.65
singles Front Mount 2.4 cu in displacement. Approximately 3 turns lock to lock on
and 6.5 on dual cylinders singles
Compact design and 6.5 on dual cylinders
Built‑in valve for positive rudder lock Compact design
Integral relief valve for over pressure protection Tilt Range of 48 Deg and 5 locking positions
Hydraulic Steering for Verado 135 to 200‑4 stroke engines Built‑in valve for positive rudder lock
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 200‑4 stroke engines
HYDRAULIC HELM PUMP -Q/S-TILT Also can be used on OptiMax with Mercury hydraulic cylinder and hoses
STEERING ACTUATOR

8M0184531 368.08
Cylinder designed to meet all Power Steering strength and performance
requirements. This cylinder is the most robust design in the market.
Includes all hardware to mount this cylinder including the strongest bolts to
attach to the engine. comes in tiller kit.
Verado 175‑200 ‑ both Power Steering or Hydraulic V6/1.5 Opti Max Hydraulic
‑1.5L Opti needs to order arm 898082A03 to provide clearance.
64-891666Q05 429.98 75‑150 4 stroke engines.
Front Mount 1.5 cu in displacement. Approximately 5 turns lock to lock for
singles MERCURY HYD BOLT-ON STEERING KIT- STD -W/O
and 10 on dual cylinders HOSES
Compact design
Tilt Range of 48 Deg and 5 locking positions
Built‑in valve for positive rudder lock STEERING
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 175‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can
be used on OptiMax with Mercury hydraulic cylinder and hoses Also can be used
on 75‑115 4 stroke and 1.5L opti 75‑115 HP

898349A02 744.47
This kit includes a standard helm (1.5Cu Inch) with all the needed
components to install the helm along with a bolt‑on cylinder with
hardware . This bolt‑on kit is the most robust hydraulic system in the
market. The cylinder was tested to all Verado standards for load and strength.
The kit also includes high strength machined stainless steel screws that are used
at each attachment point. Order Verado hoses 897982K__ series separately
Used on all Verado 135‑200 L4 engines, 75‑115 4 Cylinder 4 strokes , OptiMax
1/5L and V6 engines ( order arm 898082A03 when used on 1.5L Opti) (Use with
Power Steering Hoses 8M0046914 thru 8M00469932)

2022 OEM Rigging & Accessories Guide & Price List 249
