STEERING

HYDRAULIC HELM - BASIC SYSTEM HYDRAULIC HELM PUMP - COMPRESSION STYLE
FITTINGS

8M0050099 377.82
This hydraulic helm is a Tilt 20 CC / 1.2 Cu Inch helm with compression
style fittings. It is used with the 8M0054993 Basic cylinder. The shaft is
anodized steel with a composite tank. The pressure relief is 1000 PSI for
high torque applicactions for improved performance. (5.2 Lock to lock wheel 8M0056140 404.33
turns). Front Mount Tilt helm ‑ 1.5 cu in (25 CC.) displacement. Approximately 5
Single engine 75‑150 HP OB (Includes new 150 HP 4 stroke) turns lock to lock on singles
and 8 on dual cylinders
HYDRAULIC STEERING KIT Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection ‑ 1500 PSI (Use
Compression style fittings and hoses)
Use with cylinder 8M0184533 and hoses 8M0053474 thru 8M0053492. Use on
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
8M0183699 631.45 steering installation.
HYDRAULIC STEERING KIT- TILT HYDRAULIC HELM PUMP - COMPRESSION STYLE
FITTINGS

8M0183754 708.44
Hydraulic steering kit with tilt.
HYDRAULIC HELM PUMP - COMPRESSION STYLE
FITTINGS

8M0056141 399.37
Front Mount Standard helm ‑ 2.0 cu in (33CC.) displacement.
Approximately 4.7 turns lock to lock on singles
and 7.3 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection ‑ 1500 PSI (Use
Compression style fittings and hoses)
Use with cylinder 8M0184533 and hoses 8M0053474 thru 8M0053492. Use on
8M0056139 359.41 single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
Front Mount Standard helm ‑ 1.5 cu in (25 CC.) displacement. steering installation. STEERING
Approximately 5 turns lock to lock on singles (Use Compression style HYDRAULIC HELM PUMP - COMPRESSION STYLE
fittings and hoses) FITTINGS
and 8 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection‑ 1500 PSI
Use with cylinder 8M0184533 and hoses 8M0053474 thru 8M0053492. Use on
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
steering installation.

8M0056142 423.58
Front Mount Tilt helm ‑ 2.0 cu in (33 CC.) displacement. Approximately 4.7
turns lock to lock on singles
and 7.3 on dual cylinders
Compact design
Built‑in valve for positive rudder lock
Integral relief valve for over pressure protection ‑ 1500 PSI (Use
Compression style fittings and hoses)
Use with cylinder 8M0184533 and hoses 8M0053474 thru 8M0053492. Use on
single or multiple OptiMax powered boats. Use on Verado 4 cylinder Hydraulic
steering installation.
