Page 710 - US ACCESSORIES GUIDE (2019)

STEERING

TROLLING MOTOR TIE BAR KIT WITHOUT DRIVE UNIT
HYDRAULIC STEERING - BASIC AND HEAVY DUTY
SYSTEMS

Both the Basic and the Heavy Duty Hydraulic Systems in this section
will use the hoses listed. (8M0053474 to 8M0053492) Note that the
Basic is for single engines only ‑ 150 HP and below. The Heavy Duty
systems are for single engines above 150 HP as well as multiple
engines. Fittings are listed in this section that can be installed to the
compression style connections.

CYLINDER - HYDRAULIC - STANDARD
67-892763A24 201C92 336.53
Heavy duty auxiliary steering kit connects an auxiliary trolling motor to your main
motor. It is 1/2 inch thick. Ideal for large Walleye/ Great Lakes boats with rough
water running conditions
8M0141911 272C01 453.35
Panther Model 55‑2700 This Basic hydraulic cylinder has the same robust performance design requirement
as our heavy duty cylinder. It is qualified to the same 300,000 cycle as our other
TROLLING MOTOR TIE BAR KIT steering systems, has high strength fasteners, stainless steel arm, heavy duty triple
seal cartridges for enhanced duribilty and longevity high quality fittings using
swaged compression style hose connections.
All Single Outboard ‑ 150 HP and below
(1.5L Opti engine requires the special arm ‑ cylinder 8M0056619)
CYLINDER - HYDRAULIC - STANDARD STEERING

67-892763A14 212C17 353.61
Heavy duty auxiliary steering kit connects an auxiliary trolling motor to your main
motor. It is 1/2 inch thick. Drive bracket is 100% stainless steel. Ideal for large
Walleye/ Great Lakes boats with rough water running conditions
Panther Model 55‑2700
8M0056619 299C22 498.70
175HP+ KICKER ELECTRICAL KIT
This Basic hydraulic cylinder has the same robust performance design requirement
as our heavy duty cylinder. It is qualified to the same 300,000 cycle as our other
steering systems, has high strength fasteners, stainless steel arm, with a special
bend for clearance, heavy duty triple seal cartridges for enhanced duribilty and
longevity. High quality fittings using swaged compression style hose connections.
8M0149838 144C64 241.06 Mercury OB ‑ 1.5L OptiMax
This system allows you to run your kicker engine and use the power steering HYDRAULIC HELM - BASIC SYSTEM
system without your primary engine running. This system allows you to connect to
a deep cell battery (not your starter battery) and the system will provide normal
power steering from the wheel. The system will alert you when your auxiliary
battery is below 9.5 volts. This signal means that you must start your primary
engine to change the battery system. This kit will save the starting battery for
primary starting use only. Must select the appropriate isolator to be paired with this
system, dependent on engine configuration.
175hp+ power steering systems with a kicker engine. 200‑350 Verado 2015 (Gen
5) and newer and all 175‑300hp 3.4L and 4.6L engines.

8M0050098 304C87 508.12
This hydraulic helm is a std 20 CC / 1.2 Cu Inch helm with compression style
fittings. It is used with the 8M0054993 Basic cylinder. The shaft is anodized steel
with a composite tank. The pressure relief is 1000 PSI for high torque
applicactions for improved performance. (5.2 Lock to lock wheel turns).
Single engine 75‑150 HP ( includes new 150 HP 4 Stroke)

2019 US Accessories Guide 697
