Page 809 - US ACCESSORIES GUIDE (2019)

MERCURY PROPELLER RIGGING CHART

No. of Engine Diameter Pitch No. of Blades Boat Weight Boat Speed RH Part Number Description LH Part Number Performan
ce
Category
Single 14.38” 27 3 3000-3500 78-88 48- 18280A46 Mirage Plus 48- 18281A46 Elite
Series
Single 14.50” 25 3 3300-3800 71-81 48- 13706A46 Mirage Plus N/A Elite
Series
Single 14.63” 23 3 3700-4200 65-74 48- 13704A46 Mirage Plus 48- 13705A46 Elite
Series
Single 14.75” 21 3 4200-4700 59-66 48- 13702A46 Mirage Plus 48- 13703A46 Elite
Series
Single 15.25” 19 3 4600-5300 53-60 48- 13700A46 Mirage Plus 48- 13701A46 Elite
Series
Single 15.38” 18 3 5000-5700 50-56 48-889620A46 Mirage Plus 48-889619A46 Elite
Series
Single 15.5” 17 3 5300-6300 46-53 48- 18278A46 Mirage Plus 48- 90159A46 Elite
Series
Single 15.75” 15 3 6300-7500 39-46 48- 19838A46 Mirage Plus 48- 19841A46 Elite
Series
Single 14.62” 25 4 3300-3800 71-81 48-857032A46 Revolution 4 48-857033A46 Comp
Series
Single 14.62” 23 4 3700-4200 65-74 48-857030A46 Revolution 4 48-857031A46 Comp
Series
Twin 16.00” 23 3 5800-7200 65-74 48-8M0127053 Enertia ECO w/ 48-8M0127052 Comp
FLO-TORQ SSR HD Series
Twin 16.00” 22 3 5800-7200 65-74 48-8M0127051 Enertia ECO w/ 48-8M0127050 Comp
FLO-TORQ SSR HD Series
Twin 16.00” 21 3 7000-8300 59-66 48-8M0127049 Enertia ECO w/ 48-8M0127048 Comp
FLO-TORQ SSR HD Series
Twin 16.00” 20 3 7500-8900 56-63 48-8M0127047 Enertia ECO w/ 48-8M0127046 Comp
FLO-TORQ SSR HD Series
Twin 16.00” 19 3 8100-9600 53-60 48-8M0127045 Enertia ECO w/ 48-8M0127044 Comp
FLO-TORQ SSR HD Series
Twin 16.00” 18 3 8900-10400 65-74 48-8M0127043 Enertia ECO w/ 48-8M0127042 Comp
FLO-TORQ SSR HD Series
Twin 16.00” 17 3 9600-12200 46-53 48-8M0127041 Enertia ECO w/ 48-8M0127040 Comp
FLO-TORQ SSR HD Series
Twin 14.62” 25 4 5000-6300 71-81 48-8M0127039 Revolution 4 w/ 48-8M0127038 Comp
FLO-TORQ SSR HD Series
Twin 14.62” 23 4 5800-7200 65-74 48-8M0127037 Revolution 4 w/ 48-8M0127036 Comp
FLO-TORQ SSR HD Series
Twin 14.62” 21 4 7000-8300 59-66 48-8M0127035 Revolution 4 w/ 48-8M0127034 Comp
FLO-TORQ SSR HD Series
Twin 14.62" 20 4 7500-8900 56-63 48-8M0127033 Revolution 4 w/ 48-8M0127032 Comp
FLO-TORQ SSR HD Series
Twin 14.62” 19 4 8100-9600 53-60 48-8M0127031 Revolution 4 w/ 48-8M0127030 Comp
FLO-TORQ SSR HD Series
Twin 14.62" 18 4 8900-11200 49-56 48-8M0137924 Revolution 4 w/ 48-8M0137925 Comp
FLO-TORQ SSR HD Series
Twin 14.62” 17 4 9600-12200 46-53 48-8M0127029 Revolution 4 w/ 48-8M0127028 Comp
FLO-TORQ SSR HD Series
Twin 14.62” 15 4 11600-15300 39-46 48-8M0127027 Revolution 4 w/ 48-8M0127026 Comp
FLO-TORQ SSR HD Series
Twin 14.38” 27 3 4300-5300 78-88 48- 18280A46 Mirage Plus 48- 18281A46 Elite
Series
Twin 14.50” 25 3 5000-6300 71-81 48- 13706A46 Mirage Plus 48- 13707A46 Elite
Series
MERCURY PROPELLER RIGGING CHART 796 15.25” 19 3 3 3 8100-9600 53-60 48- 13700A46 Mirage Plus 48- 13701A46 Series
48- 13705A46
23
Twin
14.63”
Mirage Plus
65-74
48- 13704A46
5800-7200
Elite
3
Series
Elite
21
Twin
14.75”
48- 13703A46
7000-8300
59-66
48- 13702A46
Mirage Plus
3
Twin
Elite
Series
Elite
15.38”
48-889620A46
50-56
18
8900-10400
Mirage Plus
48-889619A46
Twin
Series
Elite
Twin
15.5”
48- 90159A46
48- 18278A46
Mirage Plus
17
9600-12200
46-53
Series
