MECHANICAL REMOTE CONTROLS

883710A02 159.43 MCC 4500 CONSOLE MOUNT - SINGLE ENGINE
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
The Panel Mount control features a chrome handle and comes with a 4ft. A single station control with rubberized grip on a redesigned handle
(1.22 m) trim harness with the 3 pin molex connector. All installations
require a separate Ignition/Choke assembly and T/S cables to complete offering smooth operation and quick response. Throttle only button at
the installation. The neutral safety switch leads are 6.5 ft. (1.98 m) and have a base of handle.
bullet connector on the ends. The lanyard switch leads also have bullet style
connector ends. CONSOLE MOUNT REMOTE CONTROL-GEN II
The control fits all current Mercury/Mariner outboards (with integral trim) and 1993
and newer Force outboards 40 HP and higher utilizing Mercury style cables (with
power trim).
The control uses GEN II T/S cables.
883710A03 155.25
WARNING: Cancer - www.P65Warnings.ca.gov
The Panel Mount control features a chrome handle and comes with a 4ft.
(1.22 m) trim and trailer switch harness with the 4 pin molex connector. All
installations require a separate Ignition/Choke assembly and T/S cables to
complete the installation. The neutral safety switch leads are 6.5 ft. (1.98 m) and
have a bullet connector on the ends. The lanyard switch leads also have bullet
style connector ends. Must use Gen II Throttle/Shift cables. (897978A__)
The power trim extension harness also needs to be ordered separately:
(84‑817659T01 & 84‑881125A1 = 4 pin Molex to traditional Mercury 3 blade P/T 8M0060782 187.61
connector) WARNING: Cancer - www.P65Warnings.ca.gov
(84‑865772T01 & 84‑865772T02 = 4 pin Molex to the Packard 3 pin P/T This control is designed for MIE inboards and outboards w/o power trim. All
connector) installations require an Ignition/Choke harness and T/S cables to complete
Fits all current MCM and Mercury/Mariner 3.4L outboards with external trim the installation.
cylinders. Fits MIE inboards and all current Mercury/Mariner outboards (without power trim)
BEZEL KIT-CUSTOM UPGRADE and 1993 and newer Force outboards 40 HP and higher utilizing Mercury style
cables (without power trim).
8/9.9 FourStroke engines 2005 and newer will use GEN II/SAE Premium cables.
8/9.9 generation change above S/N OR192772 and 15/20 FourStroke will use Gen
II T/S cables.
CONSOLE REMOTE CONTROL-GEN II-SINGLE

891648001 27.56
Woodgrain cover allows you to customize the look of your control. Snap out the
black inner bezel and snap in the custom bezel to enrich the appearance of your
control.
Use on 4000 Gen II Panel Mount controls‑ Lock Bar one piece design
8M0059686 198.77
BEZEL KIT-CUSTOM UPGRADE WARNING: Cancer - www.P65Warnings.ca.gov
This control features a single trim switch in the port handle for trim and
comes with the trim harness (attached to switch) with the white connector.
All installations require an Ignition/Choke harness and T/S cables to
complete the installation.
Fits all current Mercury/Mariner outboards (with integral trim) and 1993 and newer
Force outboards 40 HP and higher utilizing Mercury style cables (with power trim).
8/9.9 FourStroke engines 2005 and newer and 8/9.9 generation change above S/N
OR192772 and 15/20 FourStroke will use Gen II T/S Cable.

891648002 27.56
Burlwood Gold Woodgrain cover allows you to customize the look of your control.
Snap out the black inner bezel and snap in the custom bezel to enrich the
appearance of your control.
Use on 4000 Gen II Panel Mount controls‑ Lock Bar one piece design
