Page 126 - OEM RIGGING AND ACCESSORIES GUIDE (2021) - 8M0174477
P. 126
MECHANICAL REMOTE CONTROLS
ZERO EFFORT CONTROL DIODE KIT
844466A70 859.91 812497A 4 23.54
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING: Cancer - www.P65Warnings.ca.gov
3 throttle levers / White/ FWD CANT (w/ trim) Prevents feedback in the up trim circuits between multiple engines. Also need to
Fits Mercury/Mariner and MCM/MIE. order Diode Kit 812497A 3.
Required and only used on boats with "dual" engines when updating zero effort
ZERO EFFORT CONTROL control levers without trim switches to levers with trim switches.
DIODE KIT
844466A90 859.91
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
3 throttle levers / White/ AFT CANT (w/ trim)
Fits Mercury/Mariner and MCM/MIE.
ZERO EFFORT CONTROL
812497A 5 49.00
WARNING: Cancer - www.P65Warnings.ca.gov
Prevents feedback in the down trim circuits between multiple engines. Also need to
order Diode Kit 812497A 6.
Required and only used on boats with "triple" engines when updating zero effort
control levers without trim switches to levers with trim switches.
844634A74 1444.65 DIODE KIT
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
6 levers ‑ 2 shift & 3 throttle & 1 shift/ White/ FWD CANT (w/ trim)
Fits Mercury/Mariner and MCM/MIE.
DIODE KIT
812497A 6 49.00
WARNING: Cancer - www.P65Warnings.ca.gov
Prevents feedback in the up trim circuits between multiple engines. Also need to
order Diode Kit 812497A 5.
812497T03 23.53 Required and only used on boats with "triple" engines when updating zero effort
control levers without trim switches to levers with trim switches.
WARNING: Cancer - www.P65Warnings.ca.gov
Prevents feedback in the down trim circuits between multiple engines. Also need to
order Diode Kit 812497A 4.
Required and only used on boats with "dual" engines when updating zero effort
control levers without trim switches to levers with trim switches. MECHANICAL REMOTE CONTROLS
2021 OEM Rigging & Accessories Guide & Price List 113
