Page 228 - Quicksilver Product Guide (2020) - 8M0163242

REMOTE CONTROLS

REMOTE CONTROLS

SIDE MOUNT CONTROLS SIDE MOUNT REMOTE CONTROL
8M0103450
This control features a handle mounted power trim switch, 20 ft. (6.1 m) harness
Outboard Use only with Amp 10‑pin connector. The control will connect to the engine models below
without the use of an adapter harness.
SIDE MOUNT REMOTE CONTROL-14 PIN Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start
and power trim.
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables.
GEN II cables must be used on other engines.

SIDE MOUNT REMOTE CONTROL- 14 PIN AMP
8M0138643
This control features a handle mounted power trim switch, 15 ft. (4.58 m) harness
with Amp 14‑pin connector. The control will connect to the engine models below
without the use of an adapter.
Fits all current Mercury/Mariner outboards 6 HP and above and 1993 and newer
Force outboards 40 HP and above (with power trim).
GEN II cables must be used.
8M0138640
This control features a handle mounted power trim switch and a 15 ft. (4.58 m) SIDE MOUNT REMOTE CONTROL- 14 PIN
harness with 14 pin Deutsch connector. The control will connect to the engine
models below without the use of an adapter harness.

For 2006 and newer non DTS 25‑300 HP Outboard engines.
GEN II cables must be used.
8M0138641
This control features a handle mounted power trim switch and a 20 ft.
(6.1 m) harness with 14 pin Deutsch connector. The control will connect to the
engine models below without the use of an adapter harness.
For 2006 and newer non DTS 25‑300 HP Outboard engines.
GEN II cables must be used.
SIDE MOUNT REMOTE CONTROL- 8 PIN TRADITIONAL 8M0138642
8M0103452 This control features non ‑ power trim and a 15ft. (4.58m) harness with 14 pin
This control features a handle mounted power trim switch, 15 ft. Deutsch connector.
(4.58 m) harness, built‑in warning horn and power trim leads for front mount Fits all current Mercury/Mariner Outboards 6 HP and above (without power trim),
switch. and 1993 and newer Force Outboards 40 HP and higher utilizing Mercury cables
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and (without power trim).
newer Force outboards 40 HP and higher utilizing Mercury style cables (with power When used with a MY2005 and newer 8/9.9, 15/20 FourStroke Outboard an
trim). When used with MY2005 and newer 8/9.9/15/20 FourStroke outboards an Adapter harness is required. 2 pin connector is now included to allow for use of
adapter harness is required. SmartCraft accessories with analog gauges.
For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used. Gen II cable must be used.
GEN II cables must be used. SIDE MOUNT REMOTE CONTROL
8M0103453 8M0103454
This control features a handle mounted power trim switch, 20 ft. (6.1 m) harness, This control features a non‑power trim handle, 15 ft.(4.58 m) harness and built‑in
built‑in warning horn and includes power trim leads for front mount switch. warning horn. QUICKSILVER® RIGGING
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and Fits all current Mercury/Mariner Outboards 6 HP and above (without power trim)
newer Force outboards 40 HP and higher utilizing Mercury style cables (with power and 1993 and newer Force Outboards 40 HP and higher utilizing Mercury style
trim). When used with MY2005 and newer 8/9.9, 15/20 FourStroke outboards an cables (with power trim).
adapter harness is required. For MY2005 and newer 8/9.9 FourStroke Outboards SAE T/S cables must be
For MY2005 and newer 8/9.9 FourStroke outboards SAE T/S cables must be used. used.
GEN II cables must be used. For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
SIDE MOUNT REMOTE CONTROL- 10 PIN AMP FourStroke engines will use GEN I cables.
When used with a MY2005 and newer 8/9.9, 15/20 FourStroke Outboard an
8M0103449 Adapter harness is required.
This control features a handle mounted power trim switch, 15 ft. (4.58 m) harness GEN II cables must be used on other engines.
with Amp 10‑pin connector. The control will connect to the engine models below 8M0103451
without the use of an adapter.
Used on MY2005 and newer, 8/9.9, 15/20 FourStroke engines with electric start This control features a non ‑ trim handle and a 15 ft. (4.58 M) harness with Amp
connector and will direct connect to the engine models below without the use of an
and power trim. Adapter harness.
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables. For MY2005 and newer, 8/9.9, 15/20 HP FourStroke Outboards with electric start
GEN II cables must be used on other engines. and non‑trim.
For MY2005 and newer 8/9.9 FourStroke Outboards SAE T/S cables must be
used.
For 8/9.9 FourStroke engines generation change above S/N OR192772 and 15/20
FourStroke engines will use GEN I cables.
GEN II cables must be used on other engines.
